AVAILABLE MODELS
The permanent-electro magnetic systems for mill-
ing and grinding operations described in this manual
can be divided into the following categories:
MAGNETIC CHUCKS WITH SQUARE POLES
Series: QX and SQ/ST; HD; HP; CUBOTEC;
QX/HN; QG
MAGNETIC CHUCKS WITH PARALLEL POLES
Series: SGL; PRL; TFP1; TFP0; TPF; MDS
MAGNETIC CHUCKS WITH ROUND POLE
Series:
RPC; MILL TEC
4.1 Magnetic chucks with square poles
4.1.1 Series QX and SQ/ST
Models with a low density of poles that are particu-
larly suitable for medium and large magnetic chucks.
These models are constituted by magnetic sectors
formed by “islands” of poles, that produce a clamp-
ing force proportional to the dimensions of the parts
to machine. These models are particularly suitable to
machine medium and large parts.
