6-17
Communication
Address
Parameter
Name & Function Default Unit
Setting
Range
Control
Mode
RS232 RS485
S curve speed command acceleration time setting.
Sn209
Refer Sn208
200 msec
0
│
5000
S C45H 0209H
S curve speed command deceleration time setting.
Sn210
Refer Sn208
200 msec
0
│
5000
S C46H 020AH
Speed loop Gain 1
Sn211
Speed loop gain has a direct effect on the frequency
response bandwidth of the Speed-control loop.
Without causing vibration or noise Speed-loop-gain can be
increased to obtain a faster speed response.
If Cn025 (load Inertia ratio) is set correctly, the
speed-loop-bandwidth will equal to speed-loop-gain.
40 Hz
10
│
1500
Pi
Pe
S
530H 020BH
Speed-loop Integral time 1
Sn212
Speed loop integral element can eliminate the steady
speed error
and react to even slight speed variations.
Decreasing Integral time can improve system rigidity.
The formula below shows the relationship between Integral
time and Speed loop Gain.
ainSpeedLoopG
tTimeConsntegrationSpeedLoopI
2
1
5tan
100
x0.2
ms
1
│
5000
Pi
Pe
S
531H 020CH
Speed loop Gain 2
Sn213
Refer to Sn211
40 Hz
10
│
1500
Pi
Pe
S
53AH 020DH
Speed loop Integral time 2
Sn214
Refer to Sn212
100
x0.2
msec
1
│
5000
Pi
Pe
S
53BH 020EH
Value of zero speed
Sn215
Set the zero speed range in Sn215
When the actual speed is lower than Sn215 value, Output
contact ZS is activated.
50 rpm
0
│
4500
S 532H 020FH
Analog Speed Command Ratio
Sn216
Slope of voltage command / Speed command can be
adjusted.
Rate
rpm
rpm
/10V
100
│
6000
S 533H 0210H
To Next Page
