6-18
Communication
Address
Parameter
Name & Functions
Default
Unit
Setting
Range
Control
Mode
RS232
RS485
Analog Speed Command offset adjust
Sn217
The offset am
ount can be adjusted by this pa
rameter
.
Input Voltage (V)
Offset
Voltage
Speed
Command (rpm)
0 mV
-10000
│
10000
S 534H
021
1H
Analog speed command limited
Sn218
Setting Sn218 for limit the highest speed comman
d of
analog input.
Rate
rpm x
1.02
rpm
100
│
4500
S C1
1H
0212H
186
188
