6-34
Communication
Address
Parameter
Name & Function Default Unit
Setting
Range
Control
Mode
RS232 RS485
DI-1 Active Level
Setting Explanation
0 Low Active (short with IG24)
★
Hn601.2
1 High Active
X
0
│
1
ALL C23H 0501H
DI-2
★
Hn602
Please refer to Hn601
X
001
│
11F
ALL C24H 0502H
DI-3
★
Hn603
Please refer to Hn601
X
001
│
11F
ALL C25H 0503H
DI-4
★
Hn604
Please refer to Hn601
X
001
│
11F
ALL C26H 0504H
DI-5
★
Hn605
Please refer to Hn601
X
001
│
11F
ALL C27H 0505H
DI-6
★
Hn606
Please refer to Hn601
X
001
│
11F
ALL C28H 0506H
DI-7
★
Hn607
Please refer to Hn601
X
001
│
11F
ALL C29H 0507H
DI-8
★
Hn608
Please refer to Hn601
X
001
│
11F
ALL C2AH 0508H
DI-9
★
Hn609
Please refer to Hn601
X
001
│
11F
ALL C2BH 0509H
DI-10
★
Hn610
Please refer to Hn601
X
001
│
11F
ALL C2CH 050AH
DI-11
★
Hn611
Please refer to Hn601
X
001
│
11F
ALL C2DH 050BH
DI-12
★
Hn612
Please refer to Hn601
Refer to
the cross
reference
table on
page
5-65
X
001
│
11F
ALL C2EH 050CH
★New setting will become effective after re-cycling the power.
Warning! If any of programmable Inputs of DI-1 ~ DI-13 are set for the same type of function
then the logic state selection ( NO or NC selection) for these inputs must be the same type.
Otherwise an Alarm will be displayed. AL-07 (Abnormal DI/DO programming).
