TECO JSDAP Series User Manual

1-4
dn-08 Display Motor Standards
Cn030 Setting
Drive Model
JSDAP
Motor Model
Watt(KW) Speed(rpm)
Encoder
Specification
H1147 JSMA-SC04A7
0.4
(Rated 3.5A)
17 bit
H1151 JSMA- (P)SC04AB 2500
H1152 JSMA- (P)SC04AH 8192
H1155 JSMA-PSC04A5 15 bit(ABS)
H1157
15A(1)
JSMA-PSC04A7
0.4
(Rated 3.5A)
3000
17 bit
H1211 JSMA-PLC08AB 2500
H1212 JSMA-PLC08AH 8192
H1215 JSMA-PLC08A5 15 bit(ABS)
H1217 JSMA-PLC08A7
0.75
17 bit
H1221 JSMA-SC04AB 2500
H1222 JSMA-SC04AH 8192
H1225 JSMA-SC04A5 15 bit(ABS)
H1227 JSMA-SC04A7
0.4
(Rated 3.5A)
17 bit
H1231 JSMA- (P)SC08AB 2500
H1232 JSMA-PSC08AH 8192
H1235 JSMA-PSC08A5 15 bit(ABS)
H1237 JSMA-PSC08A7
0.75
3000
17 bit
H1241 JSMA-PMA05AB 1000 2500
H1252 JSMA-PMH05AH 8192
H1255 JSMA-PMH05A5 15 bit(ABS)
H1257 JSMA-PMH05A7
0.55
1500
17 bit
H1261 JSMA- (P)SC04AB 2500
H1262
20A
JSMA- (P)SC04AH
0.4
(Rated 3.5A)
3000
8192
