6-15
Speed-Control Parameter
Communication
Address
Parameter Name & Function Default Unit
Setting
Range
Control
Mode
RS232 RS485
Internal Speed Command 1
Sn201
In Speed control, input contacts SPD1 and SPD2
can be used to select 3 sets of internal speed
command, select for speed command 1 contact
status shows below:
Input Contact SPD2 Input Contact SPD1
0 1
Note: Input contacts status “1” (ON) and “0” (OFF)
Refer to 5-6-1 to set high or low input logic levels.
100 rpm
-4500
│
4500
S 536H 0201H
Internal Speed Command 2
Sn202
In Speed control, input contacts SPD1 and SPD2
can be used to select 3 sets of internal speed
command, select for speed command 2 contact
status shows below:
Input Contact SPD2 Input Contact SPD1
1 0
Note: Input contacts status “1” (ON) and “0” (OFF)
Refer to 5-6-1 to set high or low input logic levels.
200 rpm
-4500
│
4500
S 537H 0202H
Internal Speed Command 3
Sn203
In Speed control, input contacts SPD1 and SPD2
can be used to select 3 sets of internal speed
command, select for speed command 3 contact
status shows below:
Input Contact SPD2 Input Contact SPD1
1 1
Note: Input contacts status “1” (ON) and “0”
(OFF).
Refer to 5-6-1 to set high or low input logic levels.
300 rpm
-4500
│
4500
S 538H 0203H
Zero Speed selection Enable or Disable the zero
speed preset parameter Sn215.
Setting Explanation
0
No Action. ( Sn215 zero preset is not
effective).
Sn204
1
Set the preset value in Sn215 as zero
speed.
0 X
0
│
1
ALL 529H 0204H
Speed command accel/decel smooth method.
Setting Explanation
0
By Step response
1
Smooth Acceleration/deceleration
according to the curve defined by Sn206.
2
Linear accel/decel time constant .Defined
by Sn207
Sn205
3
S curve for Acceleration/deceleration.
Defined by Sn208.
0 X
0
│
3
S 52AH 0205H
