Communication
Address
Parameter Name & Function Default Unit
Setting
Range
Control
Mode
RS232 RS485
Internal Position Command 6 -Rotation
Number
Pn416
Please refer to Pn401
0 rev
-16000
│
16000
Pi 57CH 0715H
Internal Position Command 6-Pulse
Number
Pn417
Please refer to Pn402
0 pulse
-131072
│
131072
Pi
57EH
57FH
0716H
0717H
Internal Position Command 6-Move
Speed
Pn418
Please refer to Pn403
0 rpm
0
│
3000
Pi 57DH 0718H
Internal Position Command 7 -Rotation
Number
Pn419
Please refer to Pn401
0 rev
-16000
│
16000
Pi 580H 0719H
Internal Position Command 7-Pulse
Number
Pn420
Please refer to Pn402
0 pulse
-131072
│
131072
Pi
582H
583H
071AH
071BH
Internal Position Command 7-Move
Speed
Pn421
Please refer to Pn403
0 rpm
0
│
3000
Pi 581H 071CH
Internal Position Command 8 -Rotation
Number
Pn422
Please refer to Pn401
0 rev
-16000
│
16000
Pi 584H 071DH
Internal Position Command 8-Pulse
Number
Pn423
Please refer to Pn402
0 pulse
-131072
│
131072
Pi
586H
587H
071EH
071FH
Internal Position Command 8-Move
Speed
Pn424
Please refer to Pn403
0 rpm
0
│
3000
Pi 585H 0720H
Internal Position Command 9 -Rotation
Number
Pn425
Please refer to Pn401
0 rev
-16000
│
16000
Pi 588H 0721H
Internal Position Command 9-Pulse
Number
Pn426
Please refer to Pn402
0 pulse
-131072
│
131072
Pi
58AH
58BH
0722H
0723H
Internal Position Command 9-Move
Speed
Pn427
Please refer to Pn403
0 rpm
0
│
3000
Pi 589H 0724H
Internal Position Command 10 -Rotation
Number
Pn428
Please refer to Pn401
0 rev
-16000
│
16000
Pi 58CH 0725H
Internal Position Command 10-Pulse
Number
Pn429
Please refer to Pn402
0 pulse
-131072
│
131072
Pi
58EH
58FH
0726H
0727H
Internal Position Command 10-Move
Speed
Pn430
Please refer to Pn403
0 rpm
0
│
3000
Pi 58DH 0728H
Internal Position Command 11 -Rotation
Number
Pn431
Please refer to Pn401
0 rev
-16000
│
16000
Pi 590H 0729H
Internal Position Command 11-Pulse
Number
Pn432
Please refer to Pn402
0 pulse
-131072
│
131072
Pi
592H
593H
072AH
072BH
Internal Position Command 11-Move
Speed
Pn433
Please refer to Pn403
0 rpm
0
│
3000
Pi 591H 072CH
