TECO JSDAP Series User Manual

3-17
dn-08 Display Motor Standards
Cn030 Setting
Drive Model
JSDAP
Motor Model
Watt(KW) Speed(rpm)
Encoder
Specification
H1265 JSMA-PSC04A5 15 bit(ABS)
H1267
20A
JSMA-PSC04A7
0.4
(Rated 3.5A)
3000
17 bit
H1311 JSMA- (P)SC08AB 2500
H1312 JSMA-PSC08AH 8192
H1315 JSMA-PSC08A5 15 bit(ABS)
H1317 JSMA-PSC08A7
0.75 3000
17 bit
H1321 JSMA-PMA10AB 2500
H1322 JSMA-PMA10AH 8192
H1325 JSMA-PMA10A5 15 bit(ABS)
H1327 JSMA-PMA10A7
1000
17 bit
H1331 JSMA-PMB10AB 2500
H1332 JSMA-PMB10AH 8192
H1335 JSMA-PMB10A5 15 bit(ABS)
H1337 JSMA-PMB10A7
1.0
2000
17 bit
H1341 JSMA-PMH10AB 2500
H1342 JSMA-PMH10AH 8192
H1345 JSMA-PMH10A5 15 bit(ABS)
H1347 JSMA-PMH10A7
1500
17 bit
H1351 JSMA-PMC10AB 2500
H1352 JSMA-PMC10AH 8192
H1355 JSMA-PMC10A5 15 bit(ABS)
H1357
30A
JSMA-PMC10A7
1.0
3000
17 bit
