TECO JSDEP-15A Simplified Manual

54
Communication
Address
Parameter Name & Function Default Unit
Setting
Range
Control
Mode
RS232 RS485
Internal Position Command 4 -Rotation Number
Pn410
Please refer to Pn401
0 rev
-16000
│
16000
Pi 574H 070DH
Internal Position Command 4-Pulse Number
Pn411
Please refer to Pn402
0 pulse
-131072
│
131072
Pi
576H
577H
070EH
070FH
Internal Position Command 4-Move Speed
Pn412
Please refer to Pn403
0 rpm
0
│
3000
Pi 575H 0710H
Internal Position Command 5 -Rotation Number
Pn413
Please refer to Pn401
0 rev
-16000
│
16000
Pi 578H 0711H
Internal Position Command 5-Pulse Number
Pn414
Please refer to Pn402
0 pulse
-131072
│
131072
Pi
57AH
57BH
0712H
0713H
Internal Position Command 5-Move Speed
Pn415
Please refer to Pn403
0 rpm
0
│
3000
Pi 579H 0714H
Internal Position Command 6 -Rotation Number
Pn416
Please refer to Pn401
0 rev
-16000
│
16000
Pi 57CH 0715H
Internal Position Command 6-Pulse Number
Pn417
Please refer to Pn402
0 pulse
-131072
│
131072
Pi
57EH
57FH
0716H
0717H
Internal Position Command 6-Move Speed
Pn418
Please refer to Pn403
0 rpm
0
│
3000
Pi 57DH 0718H
Internal Position Command 7 -Rotation Number
Pn419
Please refer to Pn401
0 rev
-16000
│
16000
Pi 580H 0719H
Internal Position Command 7-Pulse Number
Pn420
Please refer to Pn402
0 pulse
-131072
│
131072
Pi
582H
583H
071AH
071BH
Internal Position Command 7-Move Speed
Pn421
Please refer to Pn403
0 rpm
0
│
3000
Pi 581H 071CH
Internal Position Command 8 -Rotation Number
Pn422
Please refer to Pn401
0 rev
-16000
│
16000
Pi 584H 071DH
Internal Position Command 8-Pulse Number
Pn423
Please refer to Pn402
0 pulse
-131072
│
131072
Pi
586H
587H
071EH
071FH
Internal Position Command 8-Move Speed
Pn424
Please refer to Pn403
0 rpm
0
│
3000
Pi 585H 0720H
Internal Position Command 9 -Rotation Number
Pn425
Please refer to Pn401
0 rev
-16000
│
16000
Pi 588H 0721H
Internal Position Command 9-Pulse Number
Pn426
Please refer to Pn402
0 pulse
-131072
│
131072
Pi
58AH
58BH
0722H
0723H
Internal Position Command 9-Move Speed
Pn427
Please refer to Pn403
0 rpm
0
│
3000
Pi 589H 0724H
Internal Position Command 10 -Rotation Number
Pn428
Please refer to Pn401
0 rev
-16000
│
16000
Pi 58CH 0725H
