※ Standard Specifications for JSMA-PSC/PLC
JSMA-P□□□□
Motor Mode Symbol Unit
SCP5 SC01 SC04 SC08 LC03 LC08
Drive Model 10A 10A/15A 15A/20A 20A/30A 15A 20A
Rated Output P
R
KW 0.05 0.1 0.4 0.75 0.3 0.75
Rated Torque T
R
N．m
0.16 0.32 1.27 2.39 0.95 2.39
Max. Torque T
max
N．m
0.48 0.95 3.82 7.16 2.86 7.16
Rated Speed N
R
rpm 3000 3000
Max. Speed N
max
rpm 4500 4200 4500 4200
Rated Current I
R
A 0.65 0.94 2.5 4.3 2.0 3.4
Max. Armature
Current
I
max
A 1.95 2.82 7.5 12.9 6.0 10.2
Torque Constant K
T
N．m/A
0.356 0.380 0.510 0.610 0.523 0.774
Induced Voltage
Constant
K
E
V/k rpm 40.4 39.8 61.1 63.8 54.8 81.4
Rotor Moment of
Inertia
J
M
Kg．cm
2
0.029 0.036 0.280 0.940 0.677 2.459
Armature Resistor Ra Ω 71.00 25.00 5.60 2.41 5.58 2.18
Armature Inductance La mH 24.3 35.0 14.5 8.0 11.6 6.8
Mechanical Time
Constant
Tm ms 1.43 0.59 0.50 0.58 1.32 0.85
Electrical Time
Constant
Te ms 0.34 1.40 2.59 3.30 2.08 3.12
Weight(Standard) W kgw 0.48 0.70 1.37 2.47 1.59 3.05
Insulation Grade ─ ─
Class B (130℃) Class F (155℃)
Operating Ambient
Temp.
T
℃
0 ~ 40
Operating Ambient
Humidity
RH % <80 <90
Storage Temp. T
℃
-20 ~ 60
Storage Humidity RH % <80 <90
1( kgf‧cm)＝0.0980665(N‧m) ； 1(gf‧cm‧s
2
)＝0.980665(kg‧cm
2
)
