TECO JSDEP-20A User Manual

3-14
dn-08 (Servo motor Model Code display)
z Use dn-08 to display servo motor code and check the servo drive and motor compatibility
according to the table below.
z If the dn08 preset is not according to the list below then contact your supplier.
z The motor model code is stored in parameter Cn30.
Motor Standards
dn-08 Display
Cn030 Setting
Drive Model Motor Model
Watt(KW) Speed(rpm)
Encoder
Specification
H1011 JSMA-PSCP5AB 0.05 2500
H1021
JSDEP-10A
JSMA-PSC01AB 0.1
3000
2500
H1111 JSMA-PSC01AB 0.1 3000 2500
H1121 JSMA-PLC03AB 2500
H1122 JSMA-PLC03AH
0.3 3000
8192
H1141 JSMA-SC04AB 2500
H1142 JSMA-SC04AH
0.4
(Rated
3.5A)
3000
8192
H1151 JSMA-PSC04AB 2500
H1152
JSDEP-15A
JSMA-PSC04AH
0.4
(Rated
2.5A)
3000
8192
H1211 JSMA-PLC08AB 2500
H1212 JSMA-PLC08AH 8192
H1231 JSMA-PSC08AB 2500
H1232 JSMA-PSC08AH
0.75 3000
8192
H1241 JSMA-PMA05AB 2500
H1242 JSMA-PMA05AH
1000
8192
H1251 JSMA-PMH05AB 2500
H1252
JSDEP-20A
JSMA-PMH05AH
0.55
1500
8192
H1311 JSMA-PSC08AB 2500
H1312 JSMA-PSC08AH
0.75 3000
8192
H1321 JSMA-PMA10AB 2500
H1322
JSDEP-30A
JSMA-PMA10AH
1.0 1000
8192
