19
E2-202/203/401/402/403:
Dimensions & Installation of class B Filter
M4x14L
Φ 4.5 TYP
25.0
60.0
76.0
156.0
145.0
134.0
See NOTE of Page 18
Unit: mm
LENGTH
MODEL
A B C D
E2-202/203/401/402/403 143.1 127.5 140 8.0
LENGTH
MODEL
E F G
E2-202/203/401/402/403 171.7 108 118
