INSTALLATION
Unpacking Instructions
1. Remove the clothes washer from the carton.
NOTE: Please dispose of packaging and
plastic bags responsibly.
2. Open the washer door and remove the
accessories from inside the washer.
3. Remove the four shipping bolts from the rear
of the washer prior to use.
4. Plug the shipping bolt holes with the supplied caps.
Choosing a location
The clothes washer should be located on a fi rm and fl at
surface. An uneven surface may cause excess operating
noise or vibration and effect the performance of the
washer.
The noise may be increased if the fl oor is
not fi rm.
It is not recommended to place on carpet
fl ooring. If this can not be avoided, place a
solid sheet under the appliance.
Choose a location which is indoor, dry, not exposed to direct sunlight, high
temperature or humidity.
It is recommended a clearance of at least 300mm away from objects and walls
on both sides and top. Ensure the clearance behind the appliance is not less
than 100mm and at least 160° clearance for the door to swing open.
Levelling the Washer (Adjustable feet)
For optimal washing performance, reduced noise and to
minimise vibration, it is important to ensure the washer is
completely fl at and level before use. Using a spirit level,
check both horizontal and vertical stability.
To adjust the feet:
1. Loosen the lock nut (A).
2. Adjust each foot (B). Turn left to raise or right to lower
as necessary.
3. Once all four feet have been adjusted and the washer
is completely level, tighten the lock nut (A).
A
B
Install supplied caps
to cover holes from
shipping bolts.
