CUBEX 360
P.
12
ENGLISH VERSION
CH12 LED Strip Speed 000-255 Speed from slow to fast
CH13 Color Macro 000-045 No Function
046-065 Red
066-085 Green
086-105 Blue
106-125 White
126-145 R&G
146-165 R&B
166-185 G&B
186-205 R&G&B&W
206-255 RGB Change Fast-Slow
CH14 Function 000-049 No Function
050-069 Auto 1
070-089 Auto 2
090-109 Auto 3
110-119 Sound (5s aer start sound mode)
120-249 No Function
Whole Reset
Channel Value Function
CH1 Pan 000-255 Pan 0-630°
CH2 Pan Fine 000-255 Pan Fine
CH3 Tilt 000-255 Tilt 0-200°
CH4 Tilt Fine 000-255 Tilt Fine
CH5 Infinite tilt 000-030 Stop
031-140 clockwise,from fast to slow
141-145 Stop
146-255 Counter-Clockwise from slow to
fast
CH6 Speed 000-255 Pan/Tilt Speed from fast to slow
CH7 Red 000-255 Red(0-100%)
Channel Instructions 16 channels
