6
ENGLISH VERSION
Fader DMX Channel Fader DMX Channel Fader DMX Chan-
nel
1/D 1 10 10 19 19
2/R 2 11 11 20 20
3/(G 3 12 12 21 21
4/B 4 13 13 21 22
5/W 5 14 14 23 23
6 6 15 15 24 24
7 7 16 16 PAN 25
8 8 17 17 TILT 26
9 9 18 18
The default fixture channels patch setting is as below:
• In the above table, R: Red, G: Green, B: Blue,
W: White, D: Dimmer.
• FIXTURE starting address + FADER position DMX
Channel - 1: DMX address.
• For example: In default fixture patch setting,
FIXTURE 1 PAN DMX channel is 25, fxiture 2
PAN DMX address is 51.
• The DMX start address of fixtures and the faders
DMX channel position can be pacthing as needed.
• In Show Design 3 you need to patch the fixture’s
DMX start address. For example, if you are patch-
ing a moving head, you must patch the pan/tilt
channels of the moving head to PAN/TILT wheels
on Show Design 3; If you are patching an LED fix-
ture, then, you must patch the Red, Green, Blue,
White and Dimmer channels to the corresponding
faders respectively. Show Design 3 will then be
able to run the built-in movements and fade in/out
eects with the patch setting.
