TECSYSTEM T119 User Manual

5
T119
TECHNICAL SPECIFICATIONS
T119
POWER SUPPLY
Supply rated values
24 -240Vac-dc
50/60HZ
Maximum ratings 20-270 Vac-dc
●
Vdc with reversible polarities
●
INPUTS
3 series of PTC inputs
●
1 series for L1 (ALARM)
●
1 series for L2 (TRIP)
●
1 series for FAN
●
Connections on removable terminal strips
●
Input channels protected against electromagnetic interference
●
OUTPUTS
2 alarm relay (ALL1 / FAULT AND ALL2) SPDT
●
1 ventilation management relay (FAN) with timed latch (5-10-20-40 min.) delay OFF SPST
●
Output relays with 5A-250Vac-res COSФ=1 contacts.
●
DIMENSIONS
48x96mm– DIN43700-depth 150mm (terminal block included)
panel cut-out
44 x 92 mm
TESTS AND PERFORMANCE
●
Assembly in compliance with EC rules
●
Protection from electrical interference EN 61000-4-4
●
Dielectric strength 1500 Vac for a min. between output relays and sensors, relays and power supply,
power supply and sensors
●
Ambient operating temperature from -20°C to + 60°C
●
Humidity 90% non-condensing
●
Self-extinguishing PPO UL94VO
●
