RT200
The following objects are present inside the box:
Control unit
Start guide and QR CODE
2 blocks for panel mounting
1
ENABLE contact terminal 2 poles pitch 5
Code: 2PL0363 - Screws tightening torque 0.5Nm
2 Supply and relay terminal 3 poles pitch 5
Code: 2PL0367 - Screws tightening torque 0.5Nm
1 PTC line connection terminal 3 poles
1 motor line terminal 4 poles pitch 5
Code: 2PL0369 - Screws tightening torque 0.5Nm
1MN0030 REV. 2
ATTENTION: always install the device using the terminals included in the pack. The use of terminals other
than those included with the control unit might cause malfunctions.
ACCESSORIES
4
