TECSYSTEM VRT200 User Manual

V
RT200

1
Drill a 92 x 92 mm hole in the panel sheet.
2
1
3
1MN0063 REV. 0
1) Control unit 2)
Panel hole dimensions (+0.8mm tolerance)
3) Identification label

Fix the unit securely with the blocks supplied.
1 2
3
4
1MN0008 REV. 0
1) Control unit 3) Fixing screw
2) Fixing block 4) Crosshead screwdriver #1X100mm
MOUNTING
8

TECSYSTEM VRT200 Specifications

General

Brand	TECSYSTEM
Model	VRT200
Category	Control Unit
Language	English
