RT600 SERIES
TECHNICAL SPECIFICATIONS
VRT600 VRT600 –U
POWER SUPPLY
Supply rated values 230 Vac ±10%
50/60 Hz
12Vac-Vdc ±10%
50/60Hz
INPUTS
1 contact enabling remote control (ENABLE)
● ●
2 motor line supply inputs 250Vac (15 A max) 50/60 Hz max
● ●
Connections on extractable terminal blocks
● ●
OUTPUTS
1 fault sensor or operating failure (FAULT) relay SPDT
● ●
Output relay with 5A-250Vac-res COSФ=1 contacts.
● ●
6 outputs M1-M2-M3-M4-M5-M6 : 250Vac max ±10% 5A max 50/60Hz. SPST
● ●
DIMENSIONS
100x100 mm– din43700-depth 131mm (terminal block included) Hole 92 x 92 mm Hole 92 x 92 mm
TEST AND PERFORMANCE
Construction in compliance with CE regulations
● ●
Protection from electrical interference EN 61000-4-4
● ●
