The following objects are present inside the box:
Control unit
Start guide and QR CODE
2 blocks for panel mounting
1 ENABLE and FAULT relay contact terminal 5 poles pitch 5
Code: 2PL0371 - Screws tightening torque 0.5Nm
1 supply terminal 3 poles pitch 5 Code: 2PL0367
Screws tightening torque 0.5Nm
2 Motor line terminals 6 poles pitch 5 Code: 2PL0372
Screws tightening torque 0.5Nm
1MN0030 REV. 2
ATTENTION: always install the device using the terminals included in the pack. The use of terminals other
than those included with the control unit might cause malfunctions.
