TECSYSTEM VRT600 - Technical Specifications

5
VRT600
TECHNICAL SPECIFICATIONS
VRT600
POWER SUPPLY
Supply rated values
85-250 Vac
50/60 Hz
INPUTS
1 contact enabling remote control (ENABLE)
●
2 motor line supply inputs 15 A max
85-250Vac
50/60Hz.
Connections on removable terminal strips
●
OUTPUTS
1 fault sensor or operating failure (FAULT) relay SPDT
●
Output relay with 5A-250Vac-res COSФ=1 contacts.
●
6 outputs M1-M2-M3-M4-M5-M6 : 5A max
85-250Vac
50/60Hz.
DIMENSIONS
100x100 mm– din43700-depth 131mm (terminal block included)
Hole 92 x 92 mm
TEST AND PERFORMANCE
Construction in compliance with CE regulations
●
Protection from electrical interference EN 61000-4-4
●
