VRT600
TECHNICAL SPECIFICATIONS
VRT600
TEST AND PERFORMANCE
Dielectric strength 1500 Vac for 1 minute: supply - relay fault, supply - remote.
●
Ambient operating temperature from –20°C to +60°C
●
Humidity 90% non-condensing
●
Housing NORYL 94 _V0
●
Absorption 7.5VA (max)
●
Protection treatment of the electronic part
Option
Front film polycarbonate IP65
●
DISPLAY AND DATA MANAGEMENT
LED’s alarm: undercurrent, overcurrent.
●
LED’s running: remote, local
●
LED’s prg setting, cal.
●
Initial AUTO-TUNING to set up motors' operation
●
Front button to START/STOP motors locally
●
Front alarm RESET button
●
Access to programming through front button
●
IMPORTANT WARNING
Before carrying out the isolation test of the electrical panel the control unit is installed on, disconnect M1-M2-
M3-M4-M5-M6 outputs and the power supply, to prevent it from being seriously damaged.
