manualfirst.Ifthisdoesnotprovideasolution,takethedehumidifiertoyourdistributor
for repair.
TECHNICAL SPECIFICATIONS
Model TD 310
Power consumption kW 0,18
Powersupply V / Hz / Ph 230/50/1
Current(nom.) A 1,0
Dehumidifyingcapacity(moisture
removalat32ºC,80%RH)
L / 24h 10
Dehumidifyingcapacity(moisture
removalat27ºC,60%RH)
L / 24h 6
Capacitywatercontainer L 2,4
Airflow(nom.)* m3/h 90
For rooms up to * m3 40 - 60
Operating range °C 5-32
Compressortype on/off
Refrigeranttype/charge r / gr R134a/130
Pressure suction / discharge bar 12/24 (max 25)
Dimensions (w x d x h) mm 321x258x435
Netweight kg 9,8
Gross weight kg 11
Sound pressure level dB(A) 40
Unit protection IP 21
Fuse rating 3,15A/250V
*Tobeusedasindication
Subject to change without prior notice.
PERFORMANCE GRAPH
10
7.5
5.0
2.5
0
3 6 9 12 15 18 21 24 27 30 33
T [°C]
[L/24h]
80 % RH
60 % RH
50 % RH
(tobeusedasindicationonly)
