1
105
M
EEGELEVERDE ONDERDELEN (voor de TS-modellen)
Fig. 3
Nummer Aanduiding van accessoires Aantal
1 Installatieplaat 1
2 P
luggen
8
3 Zelftappende schroef ‘AST 3,9 x 25 8
4 Afdichtring 1
5 Afvoerverbinding 1
6 Aansluitleiding
Vloeistof-
zijde
Ø 6,35 (< 6,5 kW-uitvoering)
Ø 9,53 (> 6,5 kW-uitvoering)
Niet meegeleverd
Gaszijde
Ø 9,53 (< 3,5 kW-uitvoering)
Ø 12,7 (≥ 3,5 kW-uitvoering)
Ø 16,0 (≥ 6,5 kW-uitvoering)
7 Afstandsbediening 1
8 Zelftappende schroef ‘B’ ST 2,9 x 10 2
9 Houder afstandsbediening 1
G
LET OP!
Behalve de bovengenoemde onderdelen moeten de overige onderdelen die tijdens de installatie
noodzakelijk zijn, afzonderlijk door de koper van de airconditioning worden aangeschaft.
8
9
7
C
B
A
6
2
3
1
Ten minste 15 cm
Ten
mi
n
s
t
e 12 cm
Te
n
m
in
ste
1
2
c
m
L
uc
htfi
l
te
r
LI
N
KS t
e
n
m
i
n
s
t
e
3
0
c
m
Luchtuitlaat
60 cm boven
VO
O
R te
n
mi
nste 200 cm
ACHTER t
en
m
i
n
ste 30 c
m
RECHTS
ten
mi
nste
60
cm
Afstandsbediening
Bevestigingsschroef
B ST 2,9 x 10-C-H
Houder afstandsbediening
Afdekplaatje
1
2
3
4
5
6
7
8
9
