SECTION 2. TORQUE SPECIFICATIONS
8 H.P. & LARGER ENGINES (EXCEPT VALVE-IN-HEAD)
INCH POUNDS NEWTON METER
Cylinder Head Bolts 180 - 240 20.3 - 27.1
Connecting Rod Lock Nuts 86 - 110 9.7 - 12.4
Mounting Flange or Cylinder Cover 100 - 130 11.3 - 14.7
Flywheel Nut 600 - 660 67.8 - 74.6
Spark Plug 220 - 280 24.9 - 31.6
Carburetor to Cylinder 72 - 96 8.1 - 10.9
Air Cleaner to Elbow 15 - 25 1.7 - 2.8
Air Cleaner Bracket to Carburetor 15 - 25 1.7 - 2.8
Tank Bracket to Housing 35 - 50 4.0 - 5.7
Tank Bracket to Cylinder (5/16'’ Lower) 150 - 200 17 - 22.6
Tank Bracket to Head Bolt 150 - 200 17 - 22.6
Starter-Top Mount Recoil 40 - 60 4.5 - 6.8
Belt Guard to Blower Housing 25 - 35 2.8 - 4.0
Flywheel Screen & Pulley 72 - 96 8.1 - 10.9
Stationary Point Screw 15 - 20 1.7 - 2.3
Blower Housing Baffle to Cylinder 72 - 96 8.1 - 10.9
Blower Housing to Baffle or Cylinder 48 - 72 5.4 - 8.1
Breaker Point Cover 15 - 25 1.7 - 2.8
Magneto Stator Mounting 72 - 96 8.1 - 10.9
Breather to Cylinder 20 - 25 2.3 - 2.8
Oil Drain Plug 3/8 18 80 - 100 9.0 - 11.3
Blower Housing Extension to Cylinder 72 - 96 8.1 - 10.9
Stub Shaft Bolts to Flywheel 100 - 125 11.3 - 14.1
Motor Generator all Mounting Bolts 65 - 100 7.4 - 11.3
NOTE: Divide by 12 for foot pounds.

Tecumseh HH100 Specifications

General

Horsepower	10 HP
Fuel Type	Gasoline
Cooling System	Air-cooled
Ignition System	Magneto
Spark Plug	Champion J8C
Displacement	163 cc (10.0 cu in)
