EC2975N Parts List
Main Board (cont.) Main Board (cont.)
Position Description Part Number Position Description Part Number
Capacitors (cont.) Capacitors (cont.)
C074 CAP ELCO 10UF 20% 16V 25-BCB100-M1X C276 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C075 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C278 CAP ELCO 22UF 20% 16V 25-BCB220-M1X
C082 CAP ELCO 470UF 20% 16V 25-BCB471-M1X C301 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
C083 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C302 CAP PE 0.033UF +/-5% 50V 27-PBC333-J0X
C084 CAP CERCO 330PF 5% 50V 26-EBP331-JC1 C303 CAP ELCO 2200UF 20% 35V 25-BEG222-M1X
C085 CAP CERCO 330PF 5% 50V 26-EBP331-JC1 C304 CAP PE 0.056UF +/-5% 50V 27-PBC563-J0X
C091 CAP CERCO 330PF 5% 50V 26-EBP331-JC1 C305 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C092 CAP CERCO 220PF 5% 50V 26-EBP221-JC1 C306 CAP ELCO 220UF +/-20% 35V 25-BEA221-M1X
C101 CAP ELCO 4.7UF +/-20% 50V 25-BFB479-M1X C307 CAP MPE 0.22UF +/-5% 50V 27-MBC224-J0X
C102 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X C308 CAP PE 0.039UF +/-5% 50V 27-PBC393-J0X
C106 CAP ELCO 10UF 20% 16V 25-BCB100-M1X C309 CAP ELCO 2200UF 20% 35V 25-BEG222-M1X
C107 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 C311 CAP ELCO 10UF +/-20% 50V 25-BFB100-M1X
C111 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C312 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C112 CAP CERCO 220PF 5% 50V 26-EBP221-JC1 C401 CAP CERCO B 0U01F 10% 500V 26-AIM103-KBX
C113 CAP MPE 0.22UF +/-5% 50V 27-MBC224-J0X C402 CAP CERCO B 3N3F 10% 500V 26-AIC332-KBX
C114 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 C403 CAP CERCO 390PF 10% 500V 26-AIC391-KBX
C121 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C411 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C124 CAP ELCO 4.7UF +/-20% 50V 25-BFB479-M1X C412 CAP MPP 3900PF +/-5% 1.6KV 27-ALQ392-J0X
C125 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C414 CAP MPP 0U0076F 5% 1.6KV 27-ALR762-J0X
C126 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C415 CAP MPP 3900PF +/-5% 1.6KV 27-ALQ392-J0X
C127 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1 C416 CAP PP 0.0092UF +/-5% 400V 27-RHQ922-J0X
C128 CAP CERCO SL TUBU 33PF 5% 50V 26-EBP330-JZ1 C417 CAP ELCO NP 4U7F 20% 50V 25-264610-M11
C202 CAP ELCO 47UF 20% 16V 25-BCB470-M1X C418 CAP PP 0.27UF +/-5% 400V 27-AHR274-J0X
C203 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C421 CAP ELCO 10UF +/-20% 200V 25-BKA100-M1X
C204 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 C422 CAP ELCO 100UF +/-20% 200V 25-BKG101-M1X
C205 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C431 CAP CERCO B 220PF 10% 500V 26-AIC221-KBX
C206 CAP ELCO 1UF 20% 50V 25-BFB109-M1X C432 CAP ELCO 1000UF 20% 35V 25-BEA102-M1X
C207 CAP PE 0.0022UF +/-5% 50V 27-PBC222-J0X C441 CAP CERCO B 220PF 10% 500V 26-AIC221-KBX
C208 CAP ELCO 0U47F 20% 50V 25-BFB478-M1X C442 CAP ELEC 10UF +/-20% 250V 25-BLA100-M1X
C209 CAP CERCO CH 12PF 5% 50V 26-EBP120-JC1 C451 CAP PP 0.056UF +/-5% 400V 27-RHQ563-J0X
C211 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X C452 CAP CERCO 2200PF 10% 50V 26-EBP222-KB1
C212 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X C471 CAP MPE 5.6NF +/-20% 100V 27-MCC562-J03
C213 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X C602 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C214 CAP ELCO 10UF 20% 16V 25-BCB100-M1X C603 CAP MPE 0.47UF 5% 50V 27-MBC474-J0X
C215 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C604 CAP MPE 0.47UF 5% 50V 27-MBC474-J0X
C217 CAP ELCO 100UF 20% 16V 25-BCB101-M1X C605 CAP ELCO 100UF +/-20% 50V 25-BFB101-M1X
C220 CAP MPE 0.22UF +/-5% 50V 27-MBC224-J0X C606 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C221 CAP PE 0.0022UF +/-5% 50V 27-PBC222-J0X C607 CAP ELCO 1000UF 20% 35V 25-BEA102-M1X
C222 CAP ELCO 10UF +/-20% 50V 25-BFB100-M1X C608 CAP ELCO 1000UF 20% 35V 25-BEA102-M1X
C223 CAP ELCO 1UF +/-10% 50V 25-GFB109-K1X C609 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
C224 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1 C610 CAP ELCO 1000UF 20% 35V 25-BEA102-M1X
C225 CAP MPE 0.47UF 5% 50V 27-MBC474-J0X C611 CAP PE 0.022UF +/-5% 50V 27-PBC223-J0X
C226 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C612 CAP PE 0.022UF +/-5% 50V 27-PBC223-J0X
C227 CAP ELCO 10UF 20% 16V 25-BCB100-M1X C631 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C228 CAP ELCO 100UF 20% 16V 25-BCB101-M1X C633 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
C229 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C634 CAP ELCO 100UF 20% 16V 25-BCB101-M1X
C230 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 C635 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
C231 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 C651 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C242 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X C652 CAP PE 0.0082UF +/-5% 50V 27-PBC822-J0X
C243 CAP MPE 0.47UF 5% 50V 27-MBC474-J0X C653 CAP PE 0.027UF +/-5% 50V 27-PBC273-J0X
C244 CAP PE 0.0047UF 5% 50V 27-PBC472-J0X C654 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C251 CAP CERCO 4700PF 10% 50V 26-EBP472-KB1 C655 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C252 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X C656 CAP PE 0.0082UF +/-5% 50V 27-PBC822-J0X
C253 CAP ELCO 1UF 20% 50V 25-BFB109-M1X C657 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
C254 CAP CERCO 100PF 5% 50V 26-EBP101-JC1 C658 CAP ELCO 100UF 20% 16V 25-BCB101-M1X
C255 CAP CERCO 100PF 5% 50V 26-EBP101-JC1 C659 CAP PE 0.027UF +/-5% 50V 27-PBC273-J0X
C256 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C661 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C257 CAP ELCO 100UF 20% 16V 25-BCB101-M1X C662 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C261 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1 C663 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C262 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1 C664 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C271 CAP ELCO 0.1UF +/-20% 50V 25-BFB108-M1X C665 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C272 CAP CERCO 100PF 5% 50V 26-EBP101-JC1 C666 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C273 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C671 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C274 CAP ELCO 47UF 20% 16V 25-BCB470-M1X C672 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C275 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C673 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
