Tedelex EC2975N - Side AV Board; Power Switch Board

EC2975N Parts List
Nicam Board (cont.)
DPC Board
Position Description Part Number Position Description Part Number
Filter Inductor Resonator Capacitors
L1001 COIL PL 10UH 5% 34-R100J2-0EX C1501 CAP PP 0.056UF +/-5% 400V 27-RHQ563-J0X
X1001 CRYSTAL 18.432M 45-OSC18M-4Y0 C1502 CAP METAL PE 0.1UF 10% 400V 27-MHM104-K0X
C1503 CAP METAL PE 0.1UF 10% 400V 27-MHM104-K0X
Integrated Circuit C1504 CAP METAL PE 0.1UF 10% 400V 27-MHM104-K0X
C1505 CAP METAL PE 0.1UF 10% 400V 27-MHM104-K0X
IC1001 IC MSP34HG B5 13-MSP34C-HGP
Filter Inductor
Resistors
L1501 COIL WIDTH 92UH 36-315340-017
R1001 RES CF 47R 5% 0W166 18-CB0470-JNX L1502 COIL CHOKE 2.4MH 36-WID242-XX1
R1002 RES CF 1K5 5% 0W166 18-CB0152-JNX
R1003 RES CF 3K3 5% 0W166 18-CB0332-JNX Miscellaneous
R1004 RES CF 1K 5% 0W166 18-CB0102-JNX
R1005 RES CF 1K 5% 0W166 18-CB0102-JNX BRACKET IF BD 67-257870-1T0
BRACKET IF BD 67-257870-2T0
R1006 RES CF 3K9 5% 0W166 18-CB0392-JNX NUT M3 65-Z3005X-23M
R1007 RES CF 3K9 5% 0W166 18-CB0392-JNX SCREW MC B M3 10MM 64-B3010X-104
R1008 RES CF 3K9 5% 0W166 18-CB0392-JNX SCREW MC P 3MM 8MM 64-P3008X-104
R1009 RES CF 3K9 5% 0W166 18-CB0392-JNX
R1010 RES CF 1K 5% 0W166 18-CB0102-JNX WASHER FIBRE 3.3MM 10MM 0.8MM 54-128700-0X0
R1011 RES CF 100R 5% 0W166 18-CB0101-JNX
Side AV Board
R1013 RES CF 1K 5% 0W166 18-CB0102-JNX
R1014 RES CF 100R 5% 0W166 18-CB0101-JNX P1601 RCA JACK 3PH YEL,WHT,RED/SW 47-322870-00G
R1016 RES CF 100R 5% 0W166 18-CB0101-JNX
R1017 RES CF 100R 5% 0W166 18-CB0101-JNX
Front Switch Board
R1018 RES CF 100R 5% 0W166 18-CB0101-JNX Resistors
R1019 RES CF 4K7 5% 0W166 18-CB0472-JNX
R1020 RES CF 4K7 5% 0W166 18-CB0472-JNX R023A RES CF 1K5 5% 0W166 18-CB0152-JNX
R024A RES CF 1K8 5% 0W166 18-CB0182-JNX
Transistors R025A RES CF 3K3 5% 0W166 18-CB0332-JNX
R026A RES CF 8K2 5% 0W166 18-CB0822-JNX
Q1001 TRANS 2SC1815Y 11-SC1815-YB1 R027A RES CF 15K 5% 0W166 18-CB0153-JNX
Q1002 TRANS 2SC1815Y 11-SC1815-YB1
Q1003 TRANS 2SC1815Y 11-SC1815-YB1 R027B RES CF 47K 5% 0W166 18-CB0473-JNX
R033A RES CF 1K 5% 0W166 18-CB0102-JNX
Miscellaneous
Switches
BRACKET IF BD 67-257870-1T0
S001A HS 6P24 160 TJC3 6Y 48-231010-00X
Power Switch Board
S002A HS 6P24 160 TJC3 6Y 48-231010-00X
S003A HS 6P24 160 TJC3 6Y 48-231010-00X
Capacitor S004A HS 6P24 160 TJC3 6Y 48-231010-00X
S005A HS 6P24 160 TJC3 6Y 48-231010-00X
C070A CAP ELCO 47UF 20% 16V 25-BCB470-M1X
S006A HS 6P24 160 TJC3 6Y 48-231010-00X
Resistors S007A HS 6P24 160 TJC3 6Y 48-231010-00X
R033B RES CF 470R 5% 0W166 18-CB0471-JNX Miscellaneous
R070A RES CF 47R 5% 0W166 18-CB0470-JNX
R070A RES CF 47R 5% 0W166 18-CB0470-JNX SCREW ST 3MM 10MMAB Qty 2 63-W3010X-AB4
Switch
Accessories
S801A SWITCH POWER 48-256460-0C0 MANUAL INSTRUCTIONS ML259+AA922
ASSY REMOTE HANDSET M13E 08-HS45E0-RM3
40.8 of 8
