EC2975 Parts List
Boards and Assemblies
CRT Base Board (cont)
Position Description Part Number Position Description Part Number
AV Side Board EC2975-V Connectors
CRT Base Board EC2975-L
DPC Board EC2975-U S501 SOCKET CRT GZ10 2 108D 47-265540-1U5
Front Switch Board EC2975-Y
Main Board EC2975-O Diodes
Power Switch Board EC2975-S D501
DIODE 1N4148 10-1N4148-AB1
Remote Handset M13E 08-HS45E0-RM3 D502 DIODE 1N4148 10-1N4148-AB1
Remote Handset M13E (alt) 08-2975NT-RMN
Secam Board EC2975-T Filters, Inductors
AV Side Board
L501 DIODE 1N4148 10-1N4148-AB1
L502 COIL CHOKE 22UH 10% 34-R220K2-1B3
P1601
RCA JACK 3PH YEL,WHT,RED/SW
47-322870-00G
L503 COIL CHOKE 22UH 10% 34-R220K2-1B3
L505
BEAD FERRITE HF70 35-237250-00X
Cabinet Front
L506 BEAD FERRITE HF70 35-237250-00X
ASSY CRT GND WIRE & HOUS 02-271380-00X
Resistors
CRT 29 inch A68ESF004X111 44-29SFLN-HF4
CRT FIBRE SHEET Qty4 54-314740-0X0
R501 RES CF 560R 5% 0W166 18-CB0561-JNX
DEGAUSSING COIL 36-294960-017 R502 RES CF 680R 5% 0W166 18-CB0681-JNX
FRONT CABINET 55-2975FC-0CNAB R503 RES CF 680R 5% 0W166 18-CB0681-JNX
R505 RES CF 560R 5% 0W166 18-CB0561-JNX
FRONT PANEL 56-344700-0HAAA R506 RES CF 680R 5% 0W166 18-CB0681-JNX
HOLDER POWER CORD 62-216340-0UA
INLAY SIDE AV 58-344790-5UIAA R508 RES CF 680R 5% 0W166 18-CB0681-JNX
KEY KNOB (OVAL) LEFT 56-HS45EK-1HABE R509 RES CF 680R 5% 0W166 18-CB0681-JNX
KEY KNOB (OVAL) RIGHT 56-HS45EK-1HABF R510 RES CF 560R 5% 0W166 18-CB0561-JNX
R511 RES CF 680R 5% 0W166 18-CB0681-JNX
KEY KNOB (OVAL) UPPER 56-HS45EK-2HABE R513 RES CF 680R 5% 0W166 18-CB0681-JNX
LENS-SENSOR & LED 56-2975LE-0HCAA
LOGO TEDELEX SILVER 56-291690-1HAAB R514 RES CF 2K7 5% 0W166 18-CB0272-JNX
PAD RUBBER 25MM 7MM Qty2 59-130460-00X R515 RES CF 1K 5% 0W166 18-CB0102-JNX
POWER CORD 3R/P W/HOUSING 51-KC0245-0CH R516 RES MO 15K 5% 2W 18-FG0153-JHX
R517 RES MO 15K 5% 2W 18-FG0153-JHX
POWER KNOB 56-2975PK-0HAAB R518 RES MO 15K 5% 2W 18-FG0153-JHX
PUSH BUTTON 56-2975FB-0HAAB
SCREW ST 3MM 10MMAB Qty12 63-W3010X-AB4 R519 RES CC 2.7K +/-10% 0W5 18-BE0272-KNX
SCREW ST 3MM 8MMAB Qty2 63-W3008X-AB4 R520 RES CC 2.7K +/-10% 0W5 18-BE0272-KNX
SCREW ST 7MM 30MMB Qty4 63-H7030X-0B4 R521 RES CC 2.7K +/-10% 0W5 18-BE0272-KNX
R522 RES CF 680R 5% 0W166 18-CB0681-JNX
SPACER CRT MOUNTING Qty4 54-205140-000
SPEAKER 80x160MM 8R 8W Qty2 42-81608F-XX0 Transistors
SPRING CRT 6MM 50MM 0.6MM 67-216790-0E0
SPRING POWER KNOB 67-346930-0E0 Q501 TRANS 2SC4544 11-SC4544-0A1
WASHER 7.5MM 20MM 2MM Qty4
65-A7520X-20E Q502 TRANS 2SC1815Y 11-SC1815-YB1
Q503 TRANS 2SC4544 11-SC4544-0A1
Cabinet Rear
Q504 TRANS 2SC1815Y 11-SC1815-YB1
Q505 TRANS 2SC4544 11-SC4544-0A1
INLAY TERMINAL BD 58-2975RI-4UIAA
PAD RUBBER 25MM 7MM Qty2 59-130460-00X Q506 TRANS 2SC1815Y 11-SC1815-YB1
PLATE MODEL NO. 58-2975MP-0UIAB Q507 TRANS 2SA562TM-0 11-A562TM-0B1
REAR CABINET 55-2975RC-0ENAA
SCREW ST 3MM 10MM BT Qty2 63-F3010X-BT3
DPC Board
SCREW ST B 4MM 20MMAB Qty11
63-B4020X-AB2
Capacitors
CRT Base Board
C1501 CAP PP 0.056UF +/-5% 400V 27-RHQ563-J0X
C1502 CAP METAL PE 0.1UF 10% 400V 27-MHM104-K0X
Capacitors
C1503 CAP METAL PE 0.1UF 10% 400V 27-MHM104-K0X
C1504 CAP METAL PE 0.1UF 10% 400V 27-MHM104-K0X
C501 CAP CERCO 390PF 5% 50V 26-EBP391-JC1
C502 CAP CERCO 390PF 5% 50V 26-EBP391-JC1
Filters, Inductors
C503 CAP CERCO 390PF 5% 50V 26-EBP391-JC1
C504 CAP ELEC 10UF +/-20% 250V 25-BLA100-M1X
L1051 COIL WIDTH 92UH 36-315340-017
C505 CAP CER 1000PF +/-10% 2KV 26-AMK102-KRX
L1502 COIL CHOKE 2.4MH 36-WID242-XX1
C506 CAP ELCO 470UF 20% 16V 25-BCB471-M1X
C508 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
C509 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
42. 2 of 8
