EC2975 Parts List
DPC Board (cont) Main Board (cont)
Position Description Part Number Position Description Part Number
Miscellaneous
Capacitors (cont)
BRACKET IF BD 67-257870-2T0
C074 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
NUT M3 65-Z3005X-23M
C075 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
SCREW MC B M3 10MM 64-B3010X-104
C082 CAP ELCO 470UF 20% 16V 25-BCB471-M1X
SCREW MC P 3MM 8MM 64-P3008X-104
C083 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
WASHER FIBRE 3.3mm 10mm 0.8mm
54-128700-0X0
C084 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
Front Switch Board
C085 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
C091 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
Resistors
C092 CAP CERCO 220PF 5% 50V 26-EBP221-JC1
40-2975MT-FBA
C101 CAP ELCO 4.7UF +/-20% 50V 25-BFB479-M1X
R027A RES CF 15K 5% 0W166 18-CB0153-JNX
C102 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X
R023A RES CF 1K5 5% 0W166 18-CB0152-JNX
R024A RES CF 1K8 5% 0W166 18-CB0182-JNX
C106 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
R025A RES CF 3K3 5% 0W166 18-CB0332-JNX
C107 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
R027B RES CF 47K 5% 0W166 18-CB0473-JNX
C111
CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
C112 CAP CERCO 220PF 5% 50V 26-EBP221-JC1
R026A RES CF 8K2 5% 0W166 18-CB0822-JNX C113 CAP MPE 0.22UF +/-5% 50V 27-MBC224-J0X
Switches
C114 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
C121 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
S001A HS 6P24 160 TJC3 6Y 48-231010-00X
C124 CAP ELCO 4.7UF +/-20% 50V 25-BFB479-M1X
S002A HS 6P24 160 TJC3 6Y 48-231010-00X
C125 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
S003A HS 6P24 160 TJC3 6Y 48-231010-00X
C126 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
S004A HS 6P24 160 TJC3 6Y 48-231010-00X
S005A HS 6P24 160 TJC3 6Y 48-231010-00X
C127 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C128 CAP CERCO SL TUBU 33PF 5% 50V 26-EBP330-JZ1
S006A HS 6P24 160 TJC3 6Y 48-231010-00X
C201 CAP PE 0.022UF +/-5% 50V 27-PBC223-J0X
S007A HS 6P24 160 TJC3 6Y 48-231010-00X
C202 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
C203 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
Miscellaneous
C204 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
SCREW ST 3MM 10MMAB Qty2 63-W3010X-AB4
C205 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
C206 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
Main Board
C207 CAP PE 0.0022UF +/-5% 50V 27-PBC222-J0X
C208 CAP ELCO 0U47F 20% 50V 25-BFB478-M1X
Capacitors
C209 CAP CERCO CH 12PF 5% 50V 26-EBP120-JC1
CAP CER 220PF +/-5% 2KV 26-AMM221-JZX C211 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X
CAP CERCO 220PF 5% 50V 26-EBP221-JC1 C212 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X
C001 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1 C213 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X
C002 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1 C214 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C004 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
C215 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
C013 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1 C217 CAP ELCO 100UF 20% 16V 25-BCB101-M1X
C021 CAP CERCO 220PF 5% 50V 26-EBP221-JC1 C220 CAP MPE 0.22UF +/-5% 50V 27-MBC224-J0X
C032 CAP CERCO 100PF 5% 50V 26-EBP101-JC1 C221 CAP PE 0.0022UF +/-5% 50V 27-PBC222-J0X
C041 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1 C222 CAP ELCO 10UF +/-20% 50V 25-BFB100-M1X
C042 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
C223
CAP ELCO 1UF +/-10% 50V 25-GFB109-K1X
C043 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1 C224
CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C044 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
C225 CAP MPE 0.47UF 5% 50V 27-MBC474-J0X
C051 CAP CERCO 39PF 5% 50V 26-EBP390-JC1
C226 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
C052 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C227 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C053 CAP CER 24PF +/-5% 50V 26-EBP240-JC1
C228 CAP ELCO 100UF 20% 16V 25-BCB101-M1X
C054 CAP CER 24PF +/-5% 50V 26-EBP240-JC1 C229 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
C055 CAP CERCO SL 30PF 5% 50V 26-EBP300-JZ1 C230 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
C056 CAP CERCO SL 30PF 5% 50V 26-EBP300-JZ1 C231 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
C061 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1 C242 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X
C062 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C243 CAP MPE 0.47UF 5% 50V 27-MBC474-J0X
C063 CAP CERCO 330PF 5% 50V 26-EBP331-JC1 C244 CAP PE 0.0047UF 5% 50V 27-PBC472-J0X
C064 CAP ELCO 100UF 20% 16V 25-BCB101-M1X C251 CAP CERCO 4700PF 10% 50V 26-EBP472-KB1
C071 CAP CERCO 100PF 5% 50V 26-EBP101-JC1 C252 CAP MPE 0.1UF +/-5% 50V 27-MBC104-J0X
C072 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1 C253 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
C073 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1
