EC2975N Parts List
Boards and Assemblies
CRT Base Board (cont.)
Position Description Part Number Position Description Part Number
CRT Base Board EC2975-L Filters, Inductors.
Main Board EC2975-O
Nicam Board EC2975-P L502 COIL CHOKE 22UH 10% 34-R220K2-1B3
Power Switch Board EC2975-S L503 COIL CHOKE 22UH 10% 34-R220K2-1B3
DPC Board EC2975-U L505 BEAD FERRITE HF70 35-237250-00X
L506 BEAD FERRITE HF70 35-237250-00X
Side AV Board EC2975-V
Front Switch Board EC2975-Y Resistors
ASSY REMOTE HANDSET M13E 08-HS45E0-RM3
R501 RES CF 560R 5% 0W166 18-CB0561-JNX
Cabinet Front R502 RES CF 680R 5% 0W166 18-CB0681-JNX
R503 RES CF 680R 5% 0W166 18-CB0681-JNX
29" CRT A68ESF004X111 44-29SFLN-HF4 R505 RES CF 560R 5% 0W166 18-CB0561-JNX
ASSY CRT GND WIRE & HOUS 02-271380-00X R506 RES CF 680R 5% 0W166 18-CB0681-JNX
CRT FIBRE SHEET Qty 4 54-314740-0X0
DEGAUSSING COIL 36-294960-017 R508 RES CF 680R 5% 0W166 18-CB0681-JNX
FRONT CABINET 55-2975FC-0CNAC R509 RES CF 680R 5% 0W166 18-CB0681-JNX
R510 RES CF 560R 5% 0W166 18-CB0561-JNX
FRONT PANEL 56-344700-0HAAA R511 RES CF 680R 5% 0W166 18-CB0681-JNX
HOLDER POWER CORD 62-216340-0UA R513 RES CF 680R 5% 0W166 18-CB0681-JNX
INLAY SIDE AV 58-344790-5UIAA
KCC'PE. WIRE BINDING L=30CM 62-216780-001 R514 RES CF 2K7 5% 0W166 18-CB0272-JNX
LENS-SENSOR & LED 56-2975LE-0HCAA R515 RES CF 1K 5% 0W166 18-CB0102-JNX
R516 RES MO 15K 5% 2W 18-FG0153-JHX
LOGO TEDELEX SILVER 56-291690-1HAAB R517 RES MO 15K 5% 2W 18-FG0153-JHX
PAD RUBBER 25MM 7MM Qty 2 59-130460-00X R518 RES MO 15K 5% 2W 18-FG0153-JHX
POWER CORD 3R/P W/HOUSING 51-KC0245-0CH
POWER KNOB 56-2975PK-0HAAB R519 RES CC 2.7K +/-10% 0W5 18-BE0272-KNX
PUSH BUTTON 56-2975FB-0HAAA R520 RES CC 2.7K +/-10% 0W5 18-BE0272-KNX
R521 RES CC 2.7K +/-10% 0W5 18-BE0272-KNX
SCREW ST 3MM 10MMAB Qty 12 63-W3010X-AB4 R522 RES CF 680R 5% 0W166 18-CB0681-JNX
SCREW ST 3MM 8MMAB Qty 2 63-W3008X-AB4
SCREW ST 7MM 30MMB Qty 4 63-H7030X-0B4 Transistors
SPACER CRT MOUNTING 2MM Qty 4 54-205140-000
SPEAKER 80x160MM 8R 8W Qty 2 42-81608F-XX0 Q501 TRANS 2SC4544 11-SC4544-0A1
Q502 TRANS 2SC1815Y 11-SC1815-YB1
SPONGE 50X20MM Qty 2 54-310140-000 Q503 TRANS 2SC4544 11-SC4544-0A1
SPRING CRT 6MM 50MM 0.6MM Qty 2 67-216790-0E0 Q504 TRANS 2SC1815Y 11-SC1815-YB1
SPRING POWER KNOB Qty 2 67-346930-0E0 Q505 TRANS 2SC4544 11-SC4544-0A1
WASHER 7.5MM 20MM 2MM Qty 4 65-A7520X-20E
Q506 TRANS 2SC1815Y 11-SC1815-YB1
Cabinet Rear Q507 TRANS 2SA562TM-0 11-A562TM-0B1
INLAY TERMINAL BD 58-2975RI-4UIAA
Main Board
PAD RUBBER 25MM 7MM Qty 2 59-130460-00X
PLATE MODEL NO 58-2975MP-0UIAC Capacitors
REAR CABINET 55-2975RC-0ENAA
SCREW ST 3MM 10MM BT Qty 2 63-F3010X-BT3 CAP CER 220PF 220PF +/-5% 2KV 26-AMM221-JZX
CAP CERCO 220PF 5% 50V 26-EBP221-JC1
SCREW ST B 4MM 20MMAB Qty 11 63-B4020X-AB2 C001 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C002 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
CRT Base Board C004 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
Capacitors C013 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C021 CAP CERCO 220PF 5% 50V 26-EBP221-JC1
C501 CAP CERCO 390PF 5% 50V 26-EBP391-JC1 C032 CAP CERCO 100PF 5% 50V 26-EBP101-JC1
C502 CAP CERCO 390PF 5% 50V 26-EBP391-JC1 C041 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
C503 CAP CERCO 390PF 5% 50V 26-EBP391-JC1 C042 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
C504 CAP ELEC 10UF +/-20% 250V 25-BLA100-M1X
C505 CAP CER 1000PF +/-10% 2KV 26-AMK102-KRX C043 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
C044 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
C506 CAP ELCO 470UF 20% 16V 25-BCB471-M1X C051 CAP CERCO 39PF 5% 50V 26-EBP390-JC1
C508 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C052 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C509 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C053 CAP CER 24PF +/-5% 50V 26-EBP240-JC1
Connectors C054 CAP CER 24PF +/-5% 50V 26-EBP240-JC1
C055 CAP CERCO SL 30PF 5% 50V 26-EBP300-JZ1
S501 SOCKET CRT GZ10 2 108D 47-265540-1U5 C056 CAP CERCO SL 30PF 5% 50V 26-EBP300-JZ1
C061 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
Diodes C062 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
D501 DIODE 1N4148 10-1N4148-AB1 C063 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
D502 DIODE 1N4148 10-1N4148-AB1 C064 CAP ELCO 100UF 20% 16V 25-BCB101-M1X
L501 DIODE 1N4148 10-1N4148-AB1 C071 CAP CERCO 100PF 5% 50V 26-EBP101-JC1
C072 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1
C073 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1
