EC2575 Parts List
Boards and Assemblies
CRT Base Board (cont.)
Position Description Part Number Position Description Part Number
MANUAL INSTRUCTIONS ML259+AA725 Resistors
CRT Base Board EC2575-L
Main Board EC2575-O R501 RES CF 560R 5% 0W166 18-CB0561-JNX
Side AV Board EC2575-V R502 RES CF 680R 5% 0W166 18-CB0681-JNX
Front Control Panel Board EC2575-Y R503 RES CF 680R 5% 0W166 18-CB0681-JNX
R505 RES CF 560R 5% 0W166 18-CB0561-JNX
Cabinet Front R506 RES CF 680R 5% 0W166 18-CB0681-JNX
ASSY -CRT GND WIRE & HOUS 02-271370-00X R508 RES CF 680R 5% 0W166 18-CB0681-JNX
CABINET FRONT 55-2575FC-1NCA R509 RES CF 680R 5% 0W166 18-CB0681-JNX
COSMETIC LENS 56-337920-0HAA R510 RES CF 560R 5% 0W166 18-CB0561-JNX
CRT 64SX502Y22-DC02 44-250FLS-FD1A R511 RES CF 680R 5% 0W166 18-CB0681-JNX
CRT FIBRE SHEET Qty 8 54-314740-0X0 R513 RES CF 680R 5% 0W166 18-CB0681-JNX
DEGAUSSING COIL XC-64A-2730-TC 36-294950-017 R514 RES CF 2K7 5% 0W166 18-CB0272-JNX
HOLDER CABLE 62-227680-0UA R515 RES CF 1K 5% 0W166 18-CB0102-JNX
HOLDER POWER CORD 62-216340-0UA R516 RES MO 15K 5% 2W 18-FG0153-JHX
LENS SENSOR 56-2575LE-1HCA R517 RES MO 15K 5% 2W 18-FG0153-JHX
LOGO PLASTIC 56-291690-1HAA R518 RES MO 15K 5% 2W 18-FG0153-JHX
PAD RUBBER 25MM 7MM Qty 4 59-130460-00X R519 RES CC 2.7K +/-10% 0W5 18-BE0272-KNX
POWER CORD 3R/P W/HOUSING 51-KC0245-0CH R520 RES CC 2.7K +/-10% 0W5 18-BE0272-KNX
POWER KNOB 56-2575PK-0HAA R521 RES CC 2.7K +/-10% 0W5 18-BE0272-KNX
POWER SW ADAPTER 62-269940-0HA R522 RES CF 680R 5% 0W166 18-CB0681-JNX
PUSH BUTTON 56-2575FB-0HAA
Transistors
SCREW ST 3MM 10MMAB Qty 4 63-W3010X-AB4
SCREW ST 3MM 12MMAB Qty 8 63-W3012X-AB4 Q501 TRANS 2SC4544 11-SC4544-0A1
SCREW ST B 3MM 10MM Qty 2 63-B3010X-BT4 Q502 TRANS 2SC1815Y 11-SC1815-YB1
SCREW ST H 6MM 25MM Qty 4 63-H6025X-0B4 Q503 TRANS 2SC4544 11-SC4544-0A1
SPACER CRT MOUNTING 2MM Qty 4 54-205140-000 Q504 TRANS 2SC1815Y 11-SC1815-YB1
Q505 TRANS 2SC4544 11-SC4544-0A1
SPEAKER 80x160MM 8OHM 8W Qty 2 42-81608F-XX1
SPONGE 50X20MM Qty 2 54-310140-000 Q506 TRANS 2SC1815Y 11-SC1815-YB1
SPRING CRT 6MM 50MM 0.6MM Qty 2 67-216790-0E0 Q507 TRANS 2SA562TM-0 11-A562TM-0B1
SPRING POWER KNOB 67-233100-0E0
WASHER 6MM 18MM 2MM Qty 4 65-A6018X-20E
Main Board
Cabinet Rear Capacitors
INLAY REAR AV 58-2575RI-4UIAA C001 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
INLAY SIDE AV 58-2575SI-5UIAA C002 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
PLATE MODEL NO. 58-2575MP-0UIAA C004 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
REAR CABINET 55-2575RC-0ENAA C013 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
SCREW ST 3MM 10MM BT Qty 2 63-F3010X-BT3 C021 CAP CERCO 220PF 5% 50V 26-EBP221-JC1
SCREW ST B 4MM 20MMAB Qty 9 63-B4020X-AB2 C032 CAP CERCO 100PF 5% 50V 26-EBP101-JC1
C041 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
CRT Base Board
C042 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
C043 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
Capacitors C044 CAP CERCO CH 15PF 5% 50V 26-EBP150-JC1
C501 CAP CERCO 390PF 5% 50V 26-EBP391-JC1 C051 CAP CERCO 39PF 5% 50V 26-EBP390-JC1
C502 CAP CERCO 390PF 5% 50V 26-EBP391-JC1 C052 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C503 CAP CERCO 470PF 5% 50V 26-EBP471-JC1 C053 CAP CER 24PF +/-5% 50V 26-EBP240-JC1
C504 CAP ELEC 10UF +/-20% 250V 25-BLA100-M1X C054 CAP CER 24PF +/-5% 50V 26-EBP240-JC1
C505 CAP CER 1000PF +/-10% 2KV 26-AMK102-KRX C055 CAP CERCO SL 30PF 5% 50V 26-EBP300-JZ1
C506 CAP ELCO 47UF +/-20% 25V 25-BDB470-M1X C056 CAP CERCO SL 30PF 5% 50V 26-EBP300-JZ1
C508 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C061 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C509 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 C062 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C063 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
Connector C064 CAP ELCO 100UF 20% 16V 25-BCB101-M1X
S501 SOCKET CRT GZS10-2-4 S1 47-265540-0U7 C070 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
C071 CAP CERCO 100PF 5% 50V 26-EBP101-JC1
Diodes C072 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1
C073 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1
D501 DIODE 1N4148 10-1N4148-AB1 C074 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
D502 DIODE 1N4148 10-1N4148-AB1
C075 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
Filters Inductors C082 CAP ELCO 470UF 20% 16V 25-BCB471-M1X
C083 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
L501 DIODE 1N4148 10-1N4148-AB1 C084 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
L502 COIL CHOKE 10UH 10% 34-R100K2-1B3 C085 CAP CERCO 330PF 5% 50V 26-EBP331-JC1
L503 COIL CHOKE 10UH 10% 34-R100K2-1B3
BEAD FERRITE HF70 Qty 2 35-237250-00X
50. 2 of 7
