EC34187 Parts List
Main Board (cont.) Front Control Board (cont.)
Position Description Part Number Position Description Part Number
Transistors (cont.) Switches
Q631 TRANS 2SC1815Y 11-SC1815-YBX S801 SWITCH POWER 48-POW001-AX0
Q633 TRANS 2SA1015Y 11-SA1015-YBX
Q711 TRANS 2SC1815Y 11-SC1815-YBX Miscellaneous
Q721 TRANS 2SA1015Y 11-SA1015-YBX
Q722 TRANS 2SD1499Q 11-SD1499-QAX FUSE HOLDER qty2 66-20516X-0B0
LED HOLDER 62-310430-0HA
Q801 TRANS 2SC4793 (VM) 11-SC4793-0AX POWER CORD 3R/P W/HOUSING 51-KC0245-0CH
Q830 TRANS HSB649A-C 11-SB649A-CAX POWER SW ADAPTER 62-269940-0HA
Q831 TRANS BF422 11-0BF422-0BX SCREW ST B 3MM 8MM AB qty6 63-B30080-AB4
Q911 TRANS 2SC1815Y 11-SC1815-YBX
Q912 TRANS 2SC1815Y 11-SC1815-YBX HS 2P22 200 TJC1-2Y 46-32269H-02X
F801 FUSE T 3.15A 250V 5x20MM 50-03150D-1GS
Q913 TRANS 2SC1815Y 11-SC1815-YBX IR1001 IR RECEIVER MODULE 11-IRR001-1X0
Q921 TRANS 2SC1815Y 11-SC1815-YBX
Q922 TRANS 2SC1815Y 11-SC1815-YBX
AV Board
Q923 TRANS 2SC1815Y 11-SC1815-YBX
Q931 TRANS 2SC1815Y 11-SC1815-YBX Connectors
Q932 TRANS 2SC1815Y 11-SC1815-YBX P1301 HS 2468 #24 150 TJC3-7Y 46-30772H-07X
Q933 TRANS 2SC1815Y 11-SC1815-YBX P1302 JACK RCA AV WHITE 47-RCA002-XX0
Q934 TRANS 2SA1015Y 11-SA1015-YBX P1303 JACK RCA JPJ5022-01-020 RED 47-239300-00X
Q963 TRANS 2SC1815Y 11-SC1815-YBX P1304 JACK RCA AV YELLOW 47-RCA003-XX0
Q964 TRANS 2SC1815Y 11-SC1815-YBX P1305 HS 2468 #24 150 TJC3-7Y 46-30772H-07X
Q971 TRANS 2SC1815Y 11-SC1815-YBX P1306 JACK RCA AV YELLOW 47-RCA003-XX0
Q981 TRANS 2SC1815Y 11-SC1815-YBX P1307 JACK RCA AV 47-RCA001-XX0
Q991 TRANS 2SC1815Y 11-SC1815-YBX P1308 JACK RCA AV WHITE 47-RCA002-XX0
P1309 JACK RCA AV YELLOW 47-RCA003-XX0
Miscellaneous P1310 JACK RCA AV 47-RCA001-XX0
HEATSINK qty2 67-H10918-4M2 P1311 JACK RCA AV WHITE 47-RCA002-XX0
M/C SCREW B 3MM 12MM 64-B30120-104 P1312 SOCKET 47-SVI001-XX0
M/C SCREW P 3x10 qty2 64-P30100-104
M/C SCREW P 3x8 qty7 64-P30080-104 Miscellaneous
MAIN BD BRACKET 62-3416MB-2UN
CABLE 75/200 RCA PLUG 200MM 41-PG0200-0KK
NUT M3 qty5 65-Z30050-23M NUT M3 qty3 67-339170-0B0
S/T SCREW W 3MM 10MM AB qty8 63-W30100-AB4 S/T SCREW W 3.5x12MM AB qty2 63-W35120-AB4
SCREW ST 3MM 10MM BT qty2 63-B30100-BT4 S/T SCREW W 3x10MM AB qty4 63-W30100-AB4
WASHER FIBRE 3.3x10x0.8MM qty2 54-128700-0X0 TERMINAL BD BRACKET 62-2911TB-1HN
TU101 TUNER ENV59D56F1X 07-389VR5-NX0
TUNER JACK 47-ANT001-XX0
Front Control Board
Side AV Board
Capacitors
P003A HS UL#24 400 TJC3-6Y 46-30790H-06X
C070A CAP ELCO 47UF 20% 10V 25-BBB470-M1X P941A RCA SOCKET RCA-3308 Y/W/R 47-RCA020-XX1
C801 CAP M PP 0.22UF 20% CB 250VAC 27-AQT224-MVH
C802 CAP M PP 0.22UF 20% CB 250VAC 27-AQT224-MVH
Key Board
Connectors Position Description Part Number
P001A HS 5P24 130 F/W TJC3/5Y 46-28155H-05X Connectors
P801 PIN BASE *2 TJC1-2A 46-28559W-02X
S802 PIN BASE *2 TJC1-2A 46-28559W-02X P003 HS 3P24 1000 F/W SCN/SCN-3Y 46-27689H-03X
P004 PIN BASE *8 46-316600-08X
Diodes
Resistors
D1001 LED RED FB205 14-LED05R-XX1
R023A RES CF 1K5 5% 0W166 18-CB0152-JNX
Filters, Inductors. R024A RES CF 1K8 5% 0W166 18-CB0182-JNX
R025A RES CF 3K3 5% 0W166 18-CB0332-JNX
T801 LINE FILTER 35 MH 36-LIF003-XX0 R026A RES CF 8K2 5% 0W166 18-CB0822-JNX
R027A RES CF 15K 5% 0W166 18-CB0153-JNX
Resistors
R027B RES CF 47K 5% 0W166 18-CB0473-JNX
R022A RES CF 8K2 5% 0W166 18-CB0822-JNX
R033A RES CF 1K 5% 0W166 18-CB0102-JNX
Accessories
R033B RES CF 470R 5% 0W166 18-CB0471-JNX
R070A RES CF 47R 5% 0W166 18-CB0470-JNX OPERATION MANUAL 72-A187BT-E121A
R801 RES H.VOLT CC 1M 5% 0W5 18-KE0105-JN3 Remote Controller 08-HS45E0-M13D
