EC2975N Parts List
Main Board (cont.) Main Board (cont.)
Position Description Part Number Position Description Part Number
Resistors (cont.) Transistors (cont.)
R940 RES CF 47R 5% 0W166 18-CB0470-JNX Q933 TRANS 2SC1815Y 11-SC1815-YB1
R945 RES CF 1K 5% 0W166 18-CB0102-JNX Q934 TRANS 2SA1015Y 11-SA1015-YB1
R946 RES CF 1K 5% 0W166 18-CB0102-JNX Q963 TRANS 2SC1815Y 11-SC1815-YB1
R947 RES CF 1K 5% 0W166 18-CB0102-JNX Q964 TRANS 2SC1815Y 11-SC1815-YB1
R948 RES CF 1K 5% 0W166 18-CB0102-JNX Q971 TRANS 2SC1815Y 11-SC1815-YB1
R951 RES CF 12K 5% 0W166 18-CB0123-JNX Q981 TRANS 2SC1815Y 11-SC1815-YB1
R952 RES CF 22K 5% 0W166 18-CB0223-JNX Q991 TRANS 2SC1815Y 11-SC1815-YB1
R960 RES CF 10K 5% 0W166 18-CB0103-JNX
R961 RES CF 10K 5% 0W166 18-CB0103-JNX Miscellaneous Electrical
R962 RES CF 10K 5% 0W166 18-CB0103-JNX
F801 FUSE 3.15AT 5X20MM 250V 50-26931D-1VS
R965 RES CF 4K7 5% 0W166 18-CB0472-JNX IR001A IR PRE-AMP TYPE HS0038A 02-270090-00B
R966 RES CF 1K 5% 0W166 18-CB0102-JNX TU101 TUNER UV1355-BK2 07-UV1355-BK2
R967 RES CF 4K7 5% 0W166 18-CB0472-JNX
R968 RES CF 1K 5% 0W166 18-CB0102-JNX Miscellaneous Mechanical
R971 RES CF 82R 5% 0W166 18-CB0820-JNX
BRACKET FOR FBT 62-31341-0HA
R972 RES CF 2K2 5% 0W166 18-CB0222-JNX HEATSINK Qty 2 67-H10918-4M2
R973 RES CF 100K 5% 0W166 18-CB0104-JNX HOLDER CABLE 62-227680-0UA
R981 RES CF 82R 5% 0W166 18-CB0820-JNX HOLDER LED 62-226920-0HA
R982 RES CF 2K2 5% 0W166 18-CB0222-JNX MAIN BD BRACKET 62-2975MB-0UN
R983 RES CF 100K 5% 0W166 18-CB0104-JNX
NUT M3 Qty 5 65-Z3005X-23M
R987 RES CF 15K 5% 0W166 18-CB0153-JNX RUBBER SPACER Qty 2 49-301480-00X
R988 RES CF 2K2 5% 0W166 18-CB0222-JNX SCREW MC M3 12 MM 64-P3012X-104
R989 RES CF 10K 5% 0W166 18-CB0103-JNX SCREW MC P 3MM 10MM Qty 2 64-P3010X-104
R991 RES CF 2K2 5% 0W166 18-CB0222-JNX SCREW MC P 3MM 8MM Qty 7 64-P3008X-104
R993 RES CF 200R +/-5% 0W66 18-CB0201-JNX
SCREW ST 3MM 10MMAB Qty 11 63-W3010X-AB4
R994 RES CF 150R 5% 0W166 18-CB0151-JNX SCREW ST 3MM 12MMAB 63-W3012X-AB4
RT801 POSISTOR T104-B80-A10 22-T104B8-0AA SCREW ST B 3MM 10MM Qty 2 63-B3010X-BT4
WASHER FIBRE 3.3MM 10MM 0.8MM
54-128700-0X0
Transistors F801 HOLDER FUSE Qty 2 66-20516X-0B0
Q001 TRANS 2SC1815Y 11-SC1815-YB1
Nicam Board
Q002 TRANS 2SC1815Y 11-SC1815-YB1
Q031 TRANS 2SC1815Y 11-SC1815-YB1 Capacitors
Q032 TRANS 2SC1815Y 11-SC1815-YB1
Q051 TRANS 2SC1815Y 11-SC1815-YB1 C1001 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
C1002 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1
Q052 FET 2SK2541 11-SK2541-0B1 C1003 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
Q061 TRANS 2SA1015Y 11-SA1015-YB1 C1004 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
Q062 TRANS BC337-40 11-0BC337-0B1 C1005 CAP ELCO 1UF 20% 50V 25-BFB109-M1X
Q091 TRANS 2N3904 11-2N3904-0B1
Q121 TRANS 2SC3779D 11-SC3779-DB1 C1006 CAP CERCO 2700PF 10% 50V 26-ABC272-KBX
C1007 CAP CERCO 2700PF 10% 50V 26-ABC272-KBX
Q211 TRANS DTA124ES 11-TA124E-SB1 C1008 CAP PE 0.0082UF +/-5% 50V 27-PBC822-J0X
Q212 FET 2SK2541 11-SK2541-0B1 C1009 CAP PE 0.0082UF +/-5% 50V 27-PBC822-J0X
Q241 TRANS 2SA1015Y 11-SA1015-YB1 C1010 CAP CERCO 470PF 5% 50V 26-EBP471-JC1
Q251 TRANS 2SC1815Y 11-SC1815-YB1
Q252 TRANS 2SC1815Y 11-SC1815-YB1 C1011 CAP CERCO 470PF 5% 50V 26-EBP471-JC1
C1012 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
Q261 TRANS 2SC1815Y 11-SC1815-YB1 C1013 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
Q401 TRANS 2SC4544 11-SC4544-0A1 C1014 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
Q412 TRANS 3DD1556 11-DD1556-0A2 C1015 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
Q451 TRANS 2SC1815Y 11-SC1815-YB1
Q631 TRANS 2SC1815Y 11-SC1815-YB1 C1016 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
C1017 CAP CER 1500PF +/-10% 50V 26-ABC152-KBX
Q633 TRANS 2SA1015Y 11-SA1015-YB1 C1018 CAP CERCO 470PF 5% 50V 26-EBP471-JC1
Q711 TRANS 2SC1815Y 11-SC1815-YB1 C1019 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
Q721 TRANS 2SA1015Y 11-SA1015-YB1 C1020 CAP ELCO 3.3UF +/-20% 50V 25-BFB339-M1X
Q722 TRANS 2SD1499Q (POWER) 11-SD1499-QA1
Q801 TRANSISTOR 2SC4793 (VM) 11-SC4793-0A1 C1021 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
C1022 CAP ELCO 10UF 20% 16V 25-BCB100-M1X
Q830 TRANSISTOR 2SB649A 11-SB649A-0A1 C1023 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1
Q831 TRANSISTOR BF422 11-0BF422-0B1 C1024 CAP CER 56PF +/-5% 50V 26-EBP560-JC1
Q911 TRANS 2SC1815Y 11-SC1815-YB1 C1025 CAP CER 56PF +/-5% 50V 26-EBP560-JC1
Q912 TRANS 2SC1815Y 11-SC1815-YB1
Q913 TRANS 2SC1815Y 11-SC1815-YB1 C1026 CAP CERCO 3P3F 0.25PF 50V 26-ABC339-CZX
C1027 CAP CERCO 3P3F 0.25PF 50V 26-ABC339-CZX
Q921 TRANS 2SC1815Y 11-SC1815-YB1 C1028 CAP CER 56PF +/-5% 50V 26-EBP560-JC1
Q922 TRANS 2SC1815Y 11-SC1815-YB1 C1029 CAP MPE 0.33UF 5% 50V 27-MBC334-J0X
Q923 TRANS 2SC1815Y 11-SC1815-YB1 C1030 CAP MPE 0.33UF 5% 50V 27-MBC334-J0X
Q931 TRANS 2SC1815Y 11-SC1815-YB1
Q932 TRANS 2SC1815Y 11-SC1815-YB1
