EC2975N Parts List
Main Board (cont.) Main Board (cont.)
Position Description Part Number Position Description Part Number
Resistors (cont.) Resistors (cont.)
R225 RES CF 10K 5% 0W166 18-CB0103-JNX R663 RES CF 22K 5% 0W166 18-CB0223-JNX
R226 RES CF 180R +/-5% OW25 18-CD0181-JMX R711 RES CF 270R 5% 0W166 18-CB0271-JNX
R227 RES CF 2K7 5% 0W166 18-CB0272-JNX R713 RES CF 2K2 5% 0W166 18-CB0222-JNX
R228 RES CF 560R 5% 0W166 18-CB0561-JNX R714 RES CF 33K 5% 0W166 18-CB0333-JNX
R229 RES CF 330R 5% 0W166 18-CB0331-JNX R715 RES CF 1K8 5% 0W166 18-CB0182-JNX
R231 RES.CF 6.2K +/-5% 0W166 18-CB0622-JNX R716 RES CF 10K 5% 0W166 18-CB0103-JNX
R232 RES CF 8K2 5% 0W166 18-CB0822-JNX R722 RES CF 10K 5% 0W166 18-CB0103-JNX
R241 RES CF 100R 5% 0W166 18-CB0101-JNX R723 RES CF 2K2 5% 0W25 18-CD0222-JMX
R243 RES CF 1K 5% 0W166 18-CB0102-JNX R724 RES CF 1K 5% 0W25 18-CD0102-JMX
R244 RES CF 12K 5% 0W166 18-CB0123-JNX R725 RES CF 3K9 5% 0W25 18-CD0392-JMX
R251 RES CF 220K 5% 0W166 18-CB0224-JNX R726 RES MO 3R9 5% 2W 18-FG0399-JHX
R252 RES CF 470R 5% 0W166 18-CB0471-JNX R727 RES CF 1K 5% 0W166 18-CB0102-JNX
R253 RES CF 100R 5% 0W166 18-CB0101-JNX R728 RES CF 56K 5% 0W166 18-CB0563-JNX
R254 RES CF 3K3 5% 0W166 18-CB0332-JNX R731 RES CF 120R 5% 0W5 18-CE0121-JNX
R255 RES CF 220R 5% 0W166 18-CB0221-JNX R757 RES CF 10K 5% 0W166 18-CB0103-JNX
R256 RES CF 330R 5% 0W166 18-CB0331-JNX R801 RES GLASS 1M 5% 0W5 18-KE0105-JNX
R258 RES CF 220R 5% 0W166 18-CB0221-JNX R802 POSISTOR S237-4.7M 22-S23747-09A
R259 RES CF 330R 5% 0W166 18-CB0331-JNX R803 RES CF 56K +/-5% 0W5 18-CE0563-JNX
R261 RES CF 220R 5% 0W166 18-CB0221-JNX R804 RES CF 56K +/-5% 0W5 18-CE0563-JNX
R262 RES CF 47K 5% 0W166 18-CB0473-JNX R805 RES CF 1K 5% 0W25 18-CD0102-JMX
R263 RES CF 47K 5% 0W166 18-CB0473-JNX R806 RES CF 1M 5% 0W5 18-CE0105-JNX
R269 RES CF 1K 5% 0W166 18-CB0102-JNX R806A RES CF 1M 5% 0W5 18-CE0105-JNX
R271 RES CF 1K 5% 0W166 18-CB0102-JNX R807 RES WIRE ROUND 0.18R 5% 2W 18-GG0188-JHX
R284 RES CF 47K 5% 0W166 18-CB0473-JNX R808 RES CF 1K 5% 0W25 18-CD0102-JMX
R286 RES CF 8K2 5% 0W166 18-CB0822-JNX R809 RES CF 47R 5% 0W25 18-CD0470-JMX
R287 RES CF 33K 5% 0W166 18-CB0333-JNX R810 RES MO 33K +/-5% 2W 18-FG0333-JHX
R288 RES CF 12K 5% 0W166 18-CB0123-JNX R811 RES CF 4R7 +/-5% 0W25 18-CD0479-JMX
R289 RES CF 33K 5% 0W166 18-CB0333-JNX R813 RES CF 2K7 5% 0W25 18-CD0272-JMX
R301 RES CF 1K 5% 0W166 18-CB0102-JNX R830 RES WIRE ROUND 0.22R 5% 2W 18-GG0228-JHX
R302 RES CF 3K3 5% 0W166 18-CB0332-JNX R833 RES CF 1K5 5% 0W166 18-CB0152-JNX
R303 RES WIRE WOUND 1R 5% 2W 18-GG0109-JHX R835 RES GLASS GLAZE 4.7M 0HM 0W5 18-KE0475-JNX
R304 RES CF 1K 5% 0W166 18-CB0102-JNX R836 RES MO 22K 5% 2W 18-FG0223-JHX
R305 RES CF 2R2 5% 0W5 18-CE0229-JNX R837 REC CF 56R +/-5% 0W25 18-CD0560-JMX
R306 RES MO 120R 5% 0W5 18-FE0121-JMX R838 RES CF 3K3 5% 0W166 18-CB0332-JNX
R307 RES MO 220R 5% 1W 18-FF0221-JGX R839 RES MO 33K +/-5% 2W 18-FG0333-JHX
R309 RES CF 560R +/-5% 0W5 18-CE0561-JNX R840 RES CF 22K 5% 0W166 18-CB0223-JNX
R311 RES WIRE ROUND 1R 5% 1W 18-GF0109-JGX R841 RES CF 3K9 5% 0W166 18-CB0392-JNX
R312 RES CF 3K9 5% 0W25 18-CD0392-JMX R842 RES CF 8R2 5% 0W25 18-CD0829-JMX
R313 RES CF 2K7 5% 0W25 18-CD0272-JMX R911 RES CF 1K 5% 0W166 18-CB0102-JNX
R314 RES CF 43K 5% 0W166 18-CB0433-JNX R912 RES CF 1K 5% 0W166 18-CB0102-JNX
R316 RES CF 10R 5% 0W25 18-CD0100-JMX R913 RES CF 82R 5% 0W166 18-CB0820-JNX
R401 RES CF 220R 5% 0W166 18-CB0221-JNX R914 RES CF 2K2 5% 0W166 18-CB0222-JNX
R402 RES MO 2K4 5% 1W 18-FF0242-JGX R915 RES CF 22K 5% 0W166 18-CB0223-JNX
R404 RES MO 8K2 5% 3W 18-FH0822-JIX R916 RES CF 22K 5% 0W166 18-CB0223-JNX
R405 RES MO 8K2 5% 3W 18-FH0822-JIX R917 RES CF 100K 5% 0W166 18-CB0104-JNX
R411 RES MO 680R 5% 1W 18-FF0681-JGX R918 RES CF 100K 5% 0W166 18-CB0104-JNX
R421 RES MO 10K 5% 1W 18-FF0103-JGX R919 RES CF 100K 5% 0W166 18-CB0104-JNX
R422 RES WIRE WOUND 1R 5% 2W 18-GG0109-JHX R920 RES CF 22K 5% 0W166 18-CB0223-JNX
R431 RES FUS 1R 5% 2W 18-EG0109-JHX R921 RES CF 1K 5% 0W166 18-CB0102-JNX
R451 RES CF 1K 5% 0W166 18-CB0102-JNX R922 RES CF 1K 5% 0W166 18-CB0102-JNX
R452 RES CF 15K 5% 0W166 18-CB0153-JNX R923 RES CF 82R 5% 0W166 18-CB0820-JNX
R461 RES FUS 3.9R +/-5% 2W 18-EG0399-JHX R924 RES CF 2K2 5% 0W166 18-CB0222-JNX
R472 RES CF 3K3 5% 0W166 18-CB0332-JNX R925 RES CF 22K 5% 0W166 18-CB0223-JNX
R601 RES CF 3K 5% 0W166 18-CB0302-JNX R926 RES CF 100K 5% 0W166 18-CB0104-JNX
R602 RES CF 3K 5% 0W166 18-CB0302-JNX R927 RES CF 100K 5% 0W166 18-CB0104-JNX
R603 RES CF 2K2 5% 0W166 18-CB0222-JNX R928 RES CF 100K 5% 0W166 18-CB0104-JNX
R604 RES CF 2K2 5% 0W166 18-CB0222-JNX R929 RES CF 100K 5% 0W166 18-CB0104-JNX
R607 RES CF 8R2 5% 0W25 18-CD0829-JMX R931 RES CF 470R 5% 0W166 18-CB0471-JNX
R608 RES CF 8R2 5% 0W25 18-CD0829-JMX R932 RES CF 470R 5% 0W166 18-CB0471-JNX
R631 RES CF 22K 5% 0W166 18-CB0223-JNX R933 RES CF 75R 5% 0W166 18-CB0750-JNX
R632 RES CF 10K 5% 0W166 18-CB0103-JNX R934 RES CF 150R 5% 0W166 18-CB0151-JNX
R633 RES CF 10K 5% 0W166 18-CB0103-JNX R935 RES CF 150R 5% 0W166 18-CB0151-JNX
R651 RES CF 100R 5% 0W166 18-CB0101-JNX R936 RES CF 1K 5% 0W166 18-CB0102-JNX
R652 RES CF 100R 5% 0W166 18-CB0101-JNX R938 RES CF 1K 5% 0W166 18-CB0102-JNX
R662 RES CF 22K 5% 0W166 18-CB0223-JNX R939 RES CF 1K 5% 0W166 18-CB0102-JNX
