Tedelex EC2975N - Page 37

EC2975N Parts List
Main Board (cont.) Main Board (cont.)
Position Description Part Number Position Description Part Number
Filters Inductors Resonators Transformers Resistors (cont.)
L051 COIL PL 22UH 5% 34-R220J2-0EX R031 RES CF 10K 5% 0W166 18-CB0103-JNX
L053 COIL PL 2.2UH 5% 34-R229J2-0EX R034 RES CF 3K3 5% 0W166 18-CB0332-JNX
L081 COIL PL 22UH 5% 34-R220J2-0EX R035 RES CF 4K7 5% 0W166 18-CB0472-JNX
L121 COIL CHOKE 1UH 10% 34-A109K2-1IX R036 RES CF 2K2 5% 0W166 18-CB0222-JNX
L201 COIL PL 100UH 5% 34-R101J2-0EX R037 RES CF 470R 5% 0W166 18-CB0471-JNX
L211 COIL PL 100UH 5% 34-R101J2-0EX R041 RES CF 2K2 5% 0W166 18-CB0222-JNX
L251 COIL PL 22UH 5% 34-R220J2-0EX R042 RES CF 2K2 5% 0W166 18-CB0222-JNX
L252 COIL PL 10UH 5% 34-R100J2-0EX R043 RES CF 2K2 5% 0W166 18-CB0222-JNX
L253 COIL PL 12UH 5% 34-R120J2-0EX R044 RES CF 2K2 5% 0W166 18-CB0222-JNX
L255 COIL PL 5U6H 5% 34-R569J2-0EX R051 RES CF 10K 5% 0W166 18-CB0103-JNX
L256 COIL PL 12UH 5% 34-R120J2-0EX R052 RES CF 47K 5% 0W166 18-CB0473-JNX
L271 COIL PL 100UH 5% 34-R101J2-0EX R053 RES CF 100K 5% 0W166 18-CB0104-JNX
L412 COIL CHOKE 0U6H 10% 34-A608K6-1BX R054 RES CF 10K 5% 0W166 18-CB0103-JNX
L413 COIL LINEARITY 31UH 36-LIN310-XX1 R055 RES CF 10K 5% 0W166 18-CB0103-JNX
L414 COIL CHOKE 15MH 36-WID153-XX1 R056 RES CF 100K 5% 0W166 18-CB0104-JNX
L801 BEAD FERRITE HF70 35-237250-00X R057 RES CF 15K 5% 0W166 18-CB0153-JNX
L838 COIL CHOKE 22UH 10% 34-R220K2-1B3 R061 RES CF 10K 5% 0W166 18-CB0103-JNX
T271 COIL IFT 236560 VCO 38-236560-00X R062 RES CF 1K 5% 0W166 18-CB0102-JNX
T401 TRANSFORMER HORIZ DRIVER 36-107483-002 R063 RES CF 1K5 5% 0W166 18-CB0152-JNX
T461 FLYBACK JF0702C 37-JF0702-C0X R064 RES CF 10R 5% 0W25 18-CD0100-JMX
T801 LINE FILTER (LCL-2826) 36-304090-002 R065 RES CF 100R 5% 0W166 18-CB0101-JNX
T802 TRANSFORMER KB49C1090 36-235480-015 R066 RES CF 4K7 5% 0W166 18-CB0472-JNX
T803 LINE FILTER 20MH 36-238300-002 R067 RES CF 1K 5% 0W166 18-CB0102-JNX
X051 CRYSTAL 8.0MHZ 45-252300-105 R071 RES CF 1K 5% 0W166 18-CB0102-JNX
X201 CRYSTAL 4.43 MHZ 45-107190-10X R072 RES CF 15K 5% 0W166 18-CB0153-JNX
Z141 SAW FILTER K3350K 38.9MHZ 45-SAW38M-9Y2 R073 RES CF 100R 5% 0W166 18-CB0101-JNX
Z251 CER TRAP TPS 6.5MHZ 45-130390-60X R074 RES CF 3K3 5% 0W166 18-CB0332-JNX
Z253 CER TRAP TPS 5.5MHZ 45-135070-60X R075 RES CF 100R 5% 0W166 18-CB0101-JNX
Z254 CER TRAP 6.0MHZ 45-137170-60X R076 RES CF 3K3 5% 0W166 18-CB0332-JNX
R077 RES CF 47R 5% 0W166 18-CB0470-JNX
Integrated Circuits
R084 RES CF 47R 5% 0W166 18-CB0470-JNX
IC001 IC TMP87CS38N M3 TSB 13-274020-00P R085 RES CF 47R 5% 0W166 18-CB0470-JNX
IC002 IC M24C08 13-M24C08-00P R091 RES CF 1K 5% 0W166 18-CB0102-JNX
IC201 IC TB1240AN 13-TB1240-ANP R092 RES CF 22K 5% 0W166 18-CB0223-JNX
IC261 IC 4052 13-000040-52P R101 RES CF 10K 5% 0W166 18-CB0103-JNX
IC301 IC TA8427K 13-00TA84-27P
R102 RES CF 10K 5% 0W166 18-CB0103-JNX
IC601 IC TDA2616 13-0TDA26-16S R103 RES CF 47R 5% 0W5 18-CE0470-JNX
IC651 IC TA1216AN 13-TA1216-ANP R111 RES CF 3K3 5% 0W166 18-CB0332-JNX
IC801 IC STR-F6656 13-STRF66-56P R112 RES CF 15K 5% 0W166 18-CB0153-JNX
IC802 IC H11A817B 13-H11A81-7BP R113 RES CF 15K 5% 0W166 18-CB0153-JNX
IC831 IC SE140N 13-00SE14-0NS
R114 RES CF 33K 5% 0W166 18-CB0333-JNX
IC841 IC L7805C-VAP 13-L7805C-VAP R115 RES CF 47K 5% 0W166 18-CB0473-JNX
IC851 IC MC7809C (LINEAR +9V 1A) 13-00MC78-09S R116 RES CF 10M 5% 0W166 18-CB0106-JNX
IC961 IC 4052 13-000040-52P R122 RES CF 56R 5% 0W166 18-CB0560-JNX
IC962 IC 4052 13-000040-52P R123 RES CF 180R 5% 0W166 18-CB0181-JNX
Resistors R124 RES CF 1K 5% 0W166 18-CB0102-JNX
R125 RES CF 470R 5% 0W166 18-CB0471-JNX
J782 RES MO 4K7 5% 0W5 18-FE0472-JMX R127 RES CF 150R 5% 0W166 18-CB0151-JNX
R003 RES CF 100R 5% 0W166 18-CB0101-JNX R203 RES CF 220R 5% 0W166 18-CB0221-JNX
R005 RES CF 10K 5% 0W166 18-CB0103-JNX R204 RES CF 1K5 5% 0W166 18-CB0152-JNX
R006 RES CF 100R 5% 0W166 18-CB0101-JNX
R007 RES CF 100R 5% 0W166 18-CB0101-JNX R205 RES CF 100K 5% 0W166 18-CB0104-JNX
R206 RES CF 100K 5% 0W166 18-CB0104-JNX
R009 RES CF 100R 5% 0W166 18-CB0101-JNX R208 RES CF 33K 5% 0W166 18-CB0333-JNX
R012 RES CF 220R 5% 0W166 18-CB0221-JNX R211 RES CF 4K7 5% 0W166 18-CB0472-JNX
R013 RES CF 3K3 5% 0W166 18-CB0332-JNX R212 RES CF 1K5 5% 0W166 18-CB0152-JNX
R014 RES CF 3K3 5% 0W166 18-CB0332-JNX
R015 RES CF 100R 5% 0W166 18-CB0101-JNX R213 RES CF 1K5 5% 0W166 18-CB0152-JNX
R214 RES CF 1K5 5% 0W166 18-CB0152-JNX
R016 RES CF 100R 5% 0W166 18-CB0101-JNX R215 RES CF 220R 5% 0W166 18-CB0221-JNX
R017 RES CF 10K 5% 0W166 18-CB0103-JNX R216 RES CF 220R 5% 0W166 18-CB0221-JNX
R021 RES CF 47R 5% 0W166 18-CB0470-JNX R217 RES CF 220R 5% 0W166 18-CB0221-JNX
R022 RES CF 8K2 5% 0W166 18-CB0822-JNX
R029 RES CF 10K 5% 0W166 18-CB0103-JNX R218 RES CF 2K2 5% 0W166 18-CB0222-JNX
R220 RES CF 1K 5% 0W166 18-CB0102-JNX
R221 RES CF 7K5 5% 0W166 18-CB0752-JNX
R222 RES CF 330R 5% 0W166 18-CB0331-JNX
R223 RES CF 330R 5% 0W166 18-CB0331-JNX
37.5 of 8
