EC2975 Parts List
Main Board (cont) Main Board (cont)
Position Description Part Number Position Description Part Number
Resistors (cont) Transistors (cont)
R946 RES CF 1K 5% 0W166 18-CB0102-JNX Q913 TRANS 2SC1815Y 11-SC1815-YB1
R947 RES CF 1K 5% 0W166 18-CB0102-JNX Q921 TRANS 2SC1815Y 11-SC1815-YB1
R948 RES CF 1K 5% 0W166 18-CB0102-JNX Q922 TRANS 2SC1815Y 11-SC1815-YB1
R951 RES CF 12K 5% 0W166 18-CB0123-JNX Q923 TRANS 2SC1815Y 11-SC1815-YB1
R952 RES CF 22K 5% 0W166 18-CB0223-JNX Q931 TRANS 2SC1815Y 11-SC1815-YB1
R953 RES CF 4K7 5% 0W166 18-CB0472-JNX Q932 TRANS 2SC1815Y 11-SC1815-YB1
R954 RES CF 4K7 5% 0W166 18-CB0472-JNX Q933 TRANS 2SC1815Y 11-SC1815-YB1
R960 RES CF 10K 5% 0W166 18-CB0103-JNX Q934 TRANS 2SA1015Y 11-SA1015-YB1
R961 RES CF 10K 5% 0W166 18-CB0103-JNX Q963 TRANS 2SC1815Y 11-SC1815-YB1
R962 RES CF 10K 5% 0W166 18-CB0103-JNX Q964 TRANS 2SC1815Y 11-SC1815-YB1
R965 RES CF 4K7 5% 0W166 18-CB0472-JNX Q971 TRANS 2SC1815Y 11-SC1815-YB1
R966 RES CF 1K 5% 0W166 18-CB0102-JNX Q981 TRANS 2SC1815Y 11-SC1815-YB1
R967 RES CF 4K7 5% 0W166 18-CB0472-JNX Q991 TRANS 2SC1815Y 11-SC1815-YB1
R968 RES CF 1K 5% 0W166 18-CB0102-JNX
R971 RES CF 82R 5% 0W166 18-CB0820-JNX Miscellaneous Electrical
R972 RES CF 2K2 5% 0W166 18-CB0222-JNX F801 FUSE 3.15AT 5X20MM 250V 50-26931D-1VS
R973 RES CF 100K 5% 0W166 18-CB0104-JNX IR001A IR PRE-AMP TYPE HS0038A 02-270090-00B
R981 RES CF 82R 5% 0W166 18-CB0820-JNX TU101 TUNER UV1355-BK2 07-UV1355-BK2
R982 RES CF 2K2 5% 0W166 18-CB0222-JNX
R983 RES CF 100K 5% 0W166 18-CB0104-JNX Miscellaneous Mechanical
R987 RES CF 15K 5% 0W166 18-CB0153-JNX BRACKET FOR FBT 62-31341-0HA
R988 RES CF 2K2 5% 0W166 18-CB0222-JNX HOLDER CABLE 62-227680-0UA
R989 RES CF 10K 5% 0W166 18-CB0103-JNX F801 HOLDER FUSE Qty2 66-20516X-0B0
R991 RES CF 2K2 5% 0W166 18-CB0222-JNX HOLDER LED 62-226920-0HA
R993 RES CF 200R +/-5% 0W66 18-CB0201-JNX MAIN BD BRACKET 62-2975MB-0UN
R994 RES CF 150R 5% 0W166 18-CB0151-JNX NUT M3 65-Z3005X-23M
RT801 POSISTOR T104-B80-A10 22-T104B8-0AA RUBBER SPACER Qty2 49-301480-00X
SCREW MC M3 12 MM 64-P3012X-104
Transistors SCREW MC P 3MM 10MM Qty2 64-P3010X-104
SCREW MC P 3MM 8MM Qty9 64-P3008X-104
Q001 TRANS 2SC1815Y 11-SC1815-YB1
Q002 TRANS 2SC1815Y 11-SC1815-YB1 SCREW ST 3MM 10MMAB Qty11 63-W3010X-AB4
Q031 TRANS 2SC1815Y 11-SC1815-YB1 SCREW ST 3MM 12MMAB 63-W3012X-AB4
Q032 TRANS 2SC1815Y 11-SC1815-YB1 SCREW ST B 3MM 10MM Qty2 63-B3010X-BT4
Q051 TRANS 2SC1815Y 11-SC1815-YB1
WASHER FIBRE 3.3 x 10 x 0.8mm Qty2
54-128700-0X0
Q052 FET 2SK2541 11-SK2541-0B1
Power Switch Board
Q061 TRANS 2SA1015Y 11-SA1015-YB1
Q062 TRANS BC337-40 11-0BC337-0B1 Capacitor
Q091 TRANS 2N3904 11-2N3904-0B1
Q121 TRANS 2SC3779D 11-SC3779-DB1 C070A CAP ELCO 47UF 20% 16V 25-BCB470-M1X
Q201 TRANS 2SC1815Y 11-SC1815-YB1 Resistors
Q211 TRANS DTA124ES 11-TA124E-SB1
Q212 FET 2SK2541 11-SK2541-0B1 R033A RES CF 1K 5% 0W166 18-CB0102-JNX
Q241 TRANS 2SA1015Y 11-SA1015-YB1 R033B RES CF 470R 5% 0W166 18-CB0471-JNX
Q251 TRANS 2SC1815Y 11-SC1815-YB1 R070A RES CF 47R 5% 0W166 18-CB0470-JNX
Q252 TRANS 2SC1815Y 11-SC1815-YB1 Switch
Q261 TRANS 2SC1815Y 11-SC1815-YB1
Q401 TRANS 2SC4544 11-SC4544-0A1 S801A SWITCH POWER 48-256460-0C0
Q412 TRANS 3DD1556 11-DD1556-0A2
Q451 TRANS 2SC1815Y 11-SC1815-YB1
Accessories
Q631 TRANS 2SC1815Y 11-SC1815-YB1 MANUAL INSTRUCTIONS ML259+AA628
Q633 TRANS 2SA1015Y 11-SA1015-YB1 Remote Handset M13E 08-HS45E0-RM3
Q711 TRANS 2SC1815Y 11-SC1815-YB1 Remote Handset M13E (alt) 08-2975NT-RMN
Q721 TRANS 2SA1015Y 11-SA1015-YB1
Q722 TRANS 2SD1499Q (POWER) 11-SD1499-QA1
Q801 TRANSISTOR 2SC4793 (VM) 11-SC4793-0A1
Q830 TRANSISTOR 2SB649A 11-SB649A-0A1
Q831 TRANS BF422 11-0BF422-0B1
Q911 TRANS 2SC1815Y 11-SC1815-YB1
Q912 TRANS 2SC1815Y 11-SC1815-YB1
