Tedelex EC2975N - Page 52

EC2575 Parts List
Main Board (cont.) Main Board (cont.)
Position Description Part Number Position Description Part Number
Capacitors (cont.) Connectors
C732 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 P911 RCA JACK 3P YEL.WHT.RED/SW 47-322900-00G
C745 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 P931 RCA JACK 3P YEL.WHT.RED/SW 47-322900-00G
C801 CAP MPP 0.22UF 20% 250VAC 27-AQT224-MVF P981 YC SOCKET DSW 14 47-271260-004
C802 CAP MPP 0.22UF 20% 250VAC 27-AQT224-MVF
C802A CAP METAL PE 0.1UF 10% 400V 27-MHM104-K0X Diodes
C803 CAP CERCO 4700PF +80-20 250VAC 26-AQK472-ZFX D031 LED HFR105 14-255670-LRX
C804 CAP CERCO 4700PF +80-20 250VAC 26-AQK472-ZFX D041 DIODE 1N4148 10-1N4148-AB1
C805 CAP CERCO B 0U01F 10% 500V 26-AIM103-KBX D042 DIODE 1N4148 10-1N4148-AB1
C806 CAP ELCO 220UF 20% 400V 25-BMJ221-M11 D043 DIODE 1N4148 10-1N4148-AB1
C807 CAP CER 220PF 220PF +/-5% 2KV 26-AMM221-JZX D044 DIODE 1N4148 10-1N4148-AB1
C808 CAP ELCO 10UF +/-20% 200V 25-BKA100-M1X D061 DIODE ZENER 5V1 5% 0W5 10-79C5V1-DB1
C809 CAP ELCO 47UF +/-20% 25V 25-BDB470-M1X D101 DIODE ZENER 5V1 5% 0W5 10-79C5V1-DB1
C810 CAP CERCO 220PF 5% 50V 26-EBP221-JC1 D111 DIODE ZENER UPC 574J 10-PC574J-DJ1
C811 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1 D211 DIODE 1N4148 10-1N4148-AB1
C812 CAP CERCO 470PF 10% 400VAC 26-APK471-KBJ D212 DIODE 1N4148 10-1N4148-AB1
C813 CAP CERCO 470PF 10% 400VAC 26-APK471-KBJ D213 DIODE 1N4148 10-1N4148-AB1
C814 CAP CER 2200PF +/-10% 1KV 26-AKK222-KR3 D215 DIODE 1N4148 10-1N4148-AB1
C815 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 D221 DIODE 1N4148 10-1N4148-AB1
C830 CAP CERCO B 220PF 10% 500V 26-AIC221-KBX D222 DIODE ZENER 4V7 5% 0W5 10-79C4V7-DB1
C831 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 D223 DIODE 1N4148 10-1N4148-AB1
C832 CAP ELCO 1000UF 20% 35V 25-BEA102-M1X D280 DIODE 1N4148 10-1N4148-AB1
C833 CAP CERCO B 220PF 10% 500V 26-AIC221-KBX D301 DIODE 1N4001 10-1N4001-EB1
C834 CAP CERCO B 0U01F 10% 500V 26-AIM103-KBX D411 DIODE BY228 10-0BY228-E01
C835 CAP ELCO 220UF 20% 200V 25-BKJ221-M1X D412 DIODE TFR104 10-TFR104-EB3
C836 CAP CERCO B 220PF 10% 500V 26-AIC221-KBX D421 DIODE TFR104 10-TFR104-EB3
C837 CAP CERCO B 0U01F 10% 500V 26-AIM103-KBX D431 DIODE TFR104 10-TFR104-EB3
C838 CAP ELCO 10UF +/-20% 200V 25-BKA100-M1X D441 DIODE TFR104 10-TFR104-EB3
C839 CAP CERCO 2200PF 20% 400VAC 26-ATK222-MEJ D471 DIODE ZENER 8.2V 5% 0.25W 10-79C8V2-DB1
C841 CAP CERCO B 220PF 10% 500V 26-AIC221-KBX D631 DIODE 1N4148 10-1N4148-AB1
C842 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 D632 DIODE 1N4148 10-1N4148-AB1
C843 CAP ELCO 100UF 20% 16V 25-BCB101-M1X D711 DIODE 1N4148 10-1N4148-AB1
C844 CAP CERCO B 220PF 10% 500V 26-AIC221-KBX D721 DIODE 1N4148 10-1N4148-AB1
C845 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 D731 DIODE ZENER 12V 5% 0W5 10-79C12V-DB1
C846 CAP ELCO 1000UF 20% 16V 25-BCA102-M1X D732 DIODE ZENER 12V 5% 0W5 10-79C12V-DB1
C847 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 D803 DIODE EG01C 10-0EG01C-EB1
C848 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 D804 DIODE EU1Z 10-00EU1Z-E01
C849 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D805 DIODE EU1Z 10-00EU1Z-E01
C854 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 D806 DIODE EU1Z 10-00EU1Z-E01
C855 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D807 DIODE ZENER 16V 5% 0.5W 10-79C16V-DB1
C856 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 D830 DIODE RU4YX 10-0RU4YX-E01
C911 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D831 DIODE RU3AM 10-0RU3AM-E01
C912 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D832 DIODE TFR104 10-TFR104-EB3
C913 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D833 DOIDE EU2YX 10-0EU2YX-E01
C921 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D834 DOIDE EU2YX 10-0EU2YX-E01
C922 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D839 DIIODE ZENER 3V9 5% 0W5 10-79C3V9-DB1
C923 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D840 ZENER DIODE 10-79C10V-DB1
C931 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D841 DIODE ZENER 2V4 5% 0W5 10-79C2V4-DB1
C932 CAP ELCO 47UF 20% 16V 25-BCB470-M1X D842 DIODE 1N4148 10-1N4148-AB1
C933 CAP ELCO 220UF 20% 16V 25-BCB221-M1X D843 DIODE IN4004 10-IN4004-EB1
C934 CAP ELCO 100UF 20% 16V 25-BCB101-M1X DB801 DIODE D3SB60 10-D3SB60-H71
C935 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 Filters Inductors Resonators Transformers.
C942 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1
C943 CAP ELCO 47UF 20% 16V 25-BCB470-M1X BEAD FERRITE HF70 Qty 2 D804 35-237250-00X
C944 CAP ELCO 100UF 20% 16V 25-BCB101-M1X BEAD FERRITE HF70 Qty 2 D830 35-237250-00X
C945 CAP CERCO 0.1UF 20% 50V 26-EBP104-ZF1 BEAD FERRITE HF70 Qty 2 D831 35-237250-00X
BEAD FERRITE HF70 Qt
y
2 D832
35
-
237250
-
00X
C952 CAP ELCO 10UF 20% 16V 25-BCB100-M1X BEAD FERRITE HF70 Qty 2 D833 35-237250-00X
C953 CAP CERCO SL TUBU 33PF 5% 50V 26-EBP330-JZ1
C961 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 BEAD FERRITE HF70 Qty 2 D834 35-237250-00X
C962 CAP CERCO 0.01UF 80-20% 50V 26-EBP103-ZF1 FERRITE BEAD BF60 Qty 2 FOR L80
1
35-139730-00X
C969 CAP ELCO 100UF 20% 16V 25-BCB101-M1X L051 COIL PL 22UH 5% 34-R220J2-0EX
L053
COIL PL 2
.
2UH 5%
34
-
R229J2
-
0EX
C971 CAP CERCO 1000PF 10% 50V 26-EBP102-KB1 L081 COIL PL 22UH 5% 34-R220J2-0EX
C981 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
C991 CAP ELCO 47UF 20% 16V 25-BCB470-M1X
T141 CAP CERCO SL 47PF 5% 50V 26-EBP470-JZ1
CAP CER 220PF 220PF +/-5% 2KV 26-AMM221-JZX
CAP CERCO 220PF 5% 50V 26-EBP221-JC1
52. 4 of 7
