EC2575 Parts List
Main Board (cont.) Main Board (cont.)
Position Description Part Number Position Description Part Number
Resistors (cont.) Transistors (cont.)
R928 RES CF 100K 5% 0W166 18-CB0104-JNX Q451 TRANS 2SC1815Y 11-SC1815-YB1
R929 RES CF 100K 5% 0W166 18-CB0104-JNX Q631 TRANS 2SC1815Y 11-SC1815-YB1
R931 RES CF 470R 5% 0W166 18-CB0471-JNX Q633 TRANS 2SA1015Y 11-SA1015-YB1
R932 RES CF 470R 5% 0W166 18-CB0471-JNX Q711 TRANS 2SC1815Y 11-SC1815-YB1
R933 RES CF 75R 5% 0W166 18-CB0750-JNX Q721 TRANS 2SA1015Y 11-SA1015-YB1
R934 RES CF 150R 5% 0W166 18-CB0151-JNX Q722 TRANS 2SD1499Q (POWER) 11-SD1499-QA1
R935 RES CF 150R 5% 0W166 18-CB0151-JNX Q801 TRANSISTOR 2SC4793 (VM) 11-SC4793-0A1
R936 RES CF 1K 5% 0W166 18-CB0102-JNX Q830 TRANSISTOR 2SB649A 11-SB649A-0A1
R938 RES CF 1K 5% 0W166 18-CB0102-JNX Q831 TRANSISTOR BF422 11-0BF422-0B1
R939 RES CF 1K 5% 0W166 18-CB0102-JNX Q911 TRANS 2SC1815Y 11-SC1815-YB1
R940 RES CF 47R 5% 0W166 18-CB0470-JNX Q912 TRANS 2SC1815Y 11-SC1815-YB1
R945 RES CF 1K 5% 0W166 18-CB0102-JNX Q913 TRANS 2SC1815Y 11-SC1815-YB1
R946 RES CF 1K 5% 0W166 18-CB0102-JNX Q921 TRANS 2SC1815Y 11-SC1815-YB1
R947 RES CF 1K 5% 0W166 18-CB0102-JNX Q922 TRANS 2SC1815Y 11-SC1815-YB1
R948 RES CF 1K 5% 0W166 18-CB0102-JNX Q923 TRANS 2SC1815Y 11-SC1815-YB1
R951 RES CF 12K 5% 0W166 18-CB0123-JNX Q931 TRANS 2SC1815Y 11-SC1815-YB1
R952 RES CF 22K 5% 0W166 18-CB0223-JNX Q932 TRANS 2SC1815Y 11-SC1815-YB1
R953 RES CF 4K7 5% 0W166 18-CB0472-JNX Q933 TRANS 2SC1815Y 11-SC1815-YB1
R954 RES CF 4K7 5% 0W166 18-CB0472-JNX Q934 TRANS 2SA1015Y 11-SA1015-YB1
R960 RES CF 10K 5% 0W166 18-CB0103-JNX Q963 TRANS 2SC1815Y 11-SC1815-YB1
R961 RES CF 10K 5% 0W166 18-CB0103-JNX Q964 TRANS 2SC1815Y 11-SC1815-YB1
R962 RES CF 10K 5% 0W166 18-CB0103-JNX Q971 TRANS 2SC1815Y 11-SC1815-YB1
R965 RES CF 4K7 5% 0W166 18-CB0472-JNX Q981 TRANS 2SC1815Y 11-SC1815-YB1
R966 RES CF 1K 5% 0W166 18-CB0102-JNX Q991 TRANS 2SC1815Y 11-SC1815-YB1
R967 RES CF 4K7 5% 0W166 18-CB0472-JNX
Miscellaneous Electrical
R968 RES CF 1K 5% 0W166 18-CB0102-JNX
R971 RES CF 82R 5% 0W166 18-CB0820-JNX F801 FUSE 3.15AT 5X20MM 250V 50-26931D-1VS
R972 RES CF 2K2 5% 0W166 18-CB0222-JNX IR001 IR PRE-AMP TYPE HS0038A 02-270090-00B
R973 RES CF 100K 5% 0W166 18-CB0104-JNX TU101 TUNER UV1355-BK2 07-UV1355-BK2
R981 RES CF 82R 5% 0W166 18-CB0820-JNX
Miscellaneous Mechanical
R982 RES CF 2K2 5% 0W166 18-CB0222-JNX
R983 RES CF 100K 5% 0W166 18-CB0104-JNX BRACKET FOR FBT 62-313410-0HA
R987 RES CF 15K 5% 0W166 18-CB0153-JNX BRACKET IF BD 67-257870-2T0
R988 RES CF 2K2 5% 0W166 18-CB0222-JNX HOLDER FUSE Qty 2 66-20516X-0B0
R989 RES CF 10K 5% 0W166 18-CB0103-JNX HOLDER LED 62-226920-0HA
MAIN BD BRACKET 62-2501MB-1UN
R991 RES CF 2K2 5% 0W166 18-CB0222-JNX
R993 RES CF 200R +/-5% 0W66 18-CB0201-JNX NUT M3 Qty 4 65-Z3005X-23M
R994 RES CF 150R 5% 0W166 18-CB0151-JNX RUBBER SPACER Qty 2 49-301480-00X
RT801 POSISTOR T104-B80-A10 22-T104B8-0AA SCREW MC M3 12 MM 64-P3012X-104
RES CF 10K 5% 0W166 18-CB0103-JNX SCREW MC P 3MM 10MM Qty 2 64-P3010X-104
SCREW MC P 3MM 8MM Qty 6 64-P3008X-104
Switches
SCREW ST 3MM 10MMAB Qty 7 63-W3010X-AB4
S801 SWITCH POWER 48-256460-0C0 SCREW ST 3MM 12MMAB 63-W3012X-AB4
Transistors
Side AV Board
Q001 TRANS 2SC1815Y 11-SC1815-YB1 P1001 RCA JACK 3PH YEL,WHT,RED/SW 47-322870-00G
Q002 TRANS 2SC1815Y 11-SC1815-YB1 P C B SIDE AV BD 40-2575MT-SIB
Q031 TRANS 2SC1815Y 11-SC1815-YB1 SCREW ST B 3MM 10MM Qty 2 63-B3010X-BT4
Q032 TRANS 2SC1815Y 11-SC1815-YB1
Q051 TRANS 2SC1815Y 11-SC1815-YB1 Front Control Board
Q052 FET 2SK2541 11-SK2541-0B1 R023A RES CF 1K5 5% 0W166 18-CB0152-JNX
Q061 TRANS 2SA1015Y 11-SA1015-YB1 R024A RES CF 1K8 5% 0W166 18-CB0182-JNX
Q062 TRANS BC337-40 11-0BC337-0B1 R025A RES CF 3K3 5% 0W166 18-CB0332-JNX
Q091 TRANS 2N3904 11-2N3904-0B1 R026A RES CF 8K2 5% 0W166 18-CB0822-JNX
Q121 TRANS 2SC3779D 11-SC3779-DB1 R027A RES CF 15K 5% 0W166 18-CB0153-JNX
Q201 TRANS 2SC1815Y 11-SC1815-YB1 R027B RES CF 47K 5% 0W166 18-CB0473-JNX
Q211 TRANS DTA124ES 11-TA124E-SB1
Q212 FET 2SK2541 11-SK2541-0B1
Accessories
Q241 TRANS 2SA1015Y 11-SA1015-YB1
Q251 TRANS 2SC1815Y 11-SC1815-YB1 MANUAL INSTRUCTIONS ML259+AA725
ASSY REMOTE HANDSET M13E 08-HS45E0-RM3
Q252 TRANS 2SC1815Y 11-SC1815-YB1
Q261 TRANS 2SC1815Y 11-SC1815-YB1
Q401 TRANS 2SC4544 11-SC4544-0A1
Q412 TRANS 3DD1556 11-DD1556-0A2
55. 7 of 7
