Tedelex EC2975N - Page 61

EC2906 Parts List
Main Board (cont.) Main Board (cont.)
Position Description Part Number Position Description Part Number
Resistors (cont.) Resistors (cont.)
R221 RES CF 7K5 5% 0W166 18-CB0752-JNX R631 RES CF 22K 5% 0W166 18-CB0223-JNX
R222 RES CF 330R 5% 0W166 18-CB0331-JNX R632A RES CF 15K 5% 0W166 18-CB0153-JNX
R223 RES CF 330R 5% 0W166 18-CB0331-JNX R633 RES CF 10K 5% 0W166 18-CB0103-JNX
R225 RES CF 10K 5% 0W166 18-CB0103-JNX R651 RES CF 100R 5% 0W166 18-CB0101-JNX
R226 RES CF 180R +/-5% OW25 18-CD0181-JMX R652 RES CF 100R 5% 0W166 18-CB0101-JNX
R227 RES CF 2K7 5% 0W166 18-CB0272-JNX R662 RES CF 22K 5% 0W166 18-CB0223-JNX
R228 RES CF 560R 5% 0W166 18-CB0561-JNX R663 RES CF 22K 5% 0W166 18-CB0223-JNX
R229 RES CF 330R 5% 0W166 18-CB0331-JNX
R711 RES CF 270R 5% 0W166 18-CB0271-JNX
R237 RES CF 10K 5% 0W166 18-CB0103-JNX
R713 RES CF 2K2 5% 0W166 18-CB0222-JNX
R241 RES CF 100R 5% 0W166 18-CB0101-JNX
R714 RES CF 33K 5% 0W166 18-CB0333-JNX
R243 RES CF 1K 5% 0W166 18-CB0102-JNX
R715 RES CF 1K8 5% 0W166 18-CB0182-JNX
R244 RES CF 12K 5% 0W166 18-CB0123-JNX
R716 RES CF 10K 5% 0W166 18-CB0103-JNX
R251 RES CF 220K 5% 0W166 18-CB0224-JNX
R722 RES CF 10K 5% 0W166 18-CB0103-JNX
R252 RES CF 470R 5% 0W166 18-CB0471-JNX
R723 RES CF 2K2 5% 0W25 18-CD0222-JMX
R253 RES CF 100R 5% 0W166 18-CB0101-JNX
R724 RES CF 1K 5% 0W25 18-CD0102-JMX
R254 RES CF 3K3 5% 0W166 18-CB0332-JNX
R725 RES CF 3K9 5% 0W25 18-CD0392-JMX
R255 RES CF 220R 5% 0W166 18-CB0221-JNX
R726 RES MO 3R9 5% 2W 18-FG0399-JHX
R256 RES CF 330R 5% 0W166 18-CB0331-JNX
R731 RES CF 120R 5% 0W5 18-CE0121-JNX
R258 RES CF 220R 5% 0W166 18-CB0221-JNX
R757 RES CF 10K 5% 0W166 18-CB0103-JNX
R259 RES CF 330R 5% 0W166 18-CB0331-JNX
R801 RES CC 1M 5% 0W5 18-KE0105-JN1
R261 RES CF 220R 5% 0W166 18-CB0221-JNX
R802 NTC 4.7OHM +/-18% 22-NTC479-XX0
R262 RES CF 47K 5% 0W166 18-CB0473-JNX
R803 RES CF 56K +/-5% 0W5 18-CE0563-JNX
R263 RES CF 47K 5% 0W166 18-CB0473-JNX
R804 RES CF 56K +/-5% 0W5 18-CE0563-JNX
R264 RES CF 220R 5% 0W166 18-CB0221-JNX
R805 RES CF 1K 5% 0W25 18-CD0102-JMX
R265 RES CF 220R 5% 0W166 18-CB0221-JNX
R806 RES CF 1M 5% 0W5 18-CE0105-JNX
R266 RES CF 220R 5% 0W166 18-CB0221-JNX
R806A RES CF 1M 5% 0W5 18-CE0105-JNX
R269 RES CF 1K 5% 0W166 18-CB0102-JNX
R807 RES MO 0.15R 5% 2W 18-GG0158-JHX
R271 RES CF 1K 5% 0W166 18-CB0102-JNX
R808 RES CF 1K 5% 0W25 18-CD0102-JMX
R273 RES CF 100K 5% 0W166 18-CB0104-JNX
R809 RES CF 47R 5% 0W25 18-CD0470-JMX
R274 RES CF 100K 5% 0W166 18-CB0104-JNX
R810 RES MO 33K +/-5% 2W 18-FG0333-JHX
R284 RES CF 47K 5% 0W166 18-CB0473-JNX
R811 RES CF 4R7 +/-5% 0W25 18-CD0479-JMX
R286 RES CF 8K2 5% 0W166 18-CB0822-JNX
R813 RES CF 2K7 5% 0W25 18-CD0272-JMX
R287 RES CF 120K 5% 0W166 18-CB0124-JNX
R830 RES WIRE ROUND 0.22R 5% 2W 18-GG0228-JHX
R288 RES CF 15K 5% 0W166 18-CB0153-JNX
R833 RES CF 1K5 5% 0W166 18-CB0152-JNX
R289 RES CF 33K 5% 0W166 18-CB0333-JNX
R835 RES VOLTAGE 8.2M 5% 1W 18-KF0825-JGX
R301 RES CF 1K 5% 0W166 18-CB0102-JNX
R836 RES MO 22K 5% 2W 18-FG0223-JHX
R302 RES CF 3K3 5% 0W166 18-CB0332-JNX
R837 REC CF 56R +/-5% 0W25 18-CD0560-JMX
R303 RES MO 4R7 5% 2W 18-FG0479-JHX
R838 RES CF 3K3 5% 0W166 18-CB0332-JNX
R304 RES CF 1K 5% 0W166 18-CB0102-JNX
R839 RES MO 33K +/-5% 2W 18-FG0333-JHX
R305 RES CF 2R2 5% 0W5 18-CE0229-JNX
R840 RES CF 22K 5% 0W166 18-CB0223-JNX
R306 RES MO 120R 5% 0W5 18-FE0121-JMX
R841 RES CF 3K9 5% 0W166 18-CB0392-JNX
R307 RES MO 220R 5% 1W 18-FF0221-JGX
R842 RES CF 8R2 5% 0W25 18-CD0829-JMX
R311 RES WIRE ROUND 1R 5% 1W 18-GF0109-JGX
R911 RES CF 1K 5% 0W166 18-CB0102-JNX
R312 RES CF 4K7 5% 0W25 18-CD0472-JMX
R912 RES CF 1K 5% 0W166 18-CB0102-JNX
R313 RES CF 2K7 5% 0W25 18-CD0272-JMX
R913 RES CF 82R 5% 0W166 18-CB0820-JNX
R314 RES CF 43K 5% 0W166 18-CB0433-JNX
R914 RES CF 2K2 5% 0W166 18-CB0222-JNX
R315 RES CF 1.5K +/-5% 0W5 18-CE0152-JNX
R915 RES CF 22K 5% 0W166 18-CB0223-JNX
R401 RES CF 220R 5% 0W166 18-CB0221-JNX
R916 RES CF 22K 5% 0W166 18-CB0223-JNX
R402 RES MO 2K4 5% 1W 18-FF0242-JGX
R917 RES CF 100K 5% 0W166 18-CB0104-JNX
R404 RES CEMENT 3K +/-10% 7W 18-GM0302-KTX
R918 RES CF 100K 5% 0W166 18-CB0104-JNX
R411 RES MO 680R 5% 1W 18-FF0681-JGX
R919 RES CF 100K 5% 0W166 18-CB0104-JNX
R421 RES MO 10K 5% 1W 18-FF0103-JGX
R920 RES CF 22K 5% 0W166 18-CB0223-JNX
R422 RES WIRE WOUND 1R 5% 2W 18-GG0109-JHX
R921 RES CF 1K 5% 0W166 18-CB0102-JNX
R431 RES FUS 1R 5% 2W 18-EG0109-JHX
R922 RES CF 1K 5% 0W166 18-CB0102-JNX
R451 RES CF 1K 5% 0W166 18-CB0102-JNX
R923 RES CF 82R 5% 0W166 18-CB0820-JNX
R452 RES CF 15K 5% 0W166 18-CB0153-JNX
R924 RES CF 2K2 5% 0W166 18-CB0222-JNX
R461 RES M O 2.2OHM +/-5% 2W 18-FG0229-JHX
R925 RES CF 22K 5% 0W166 18-CB0223-JNX
R471 RES MO 4K7 5% 0W5 18-FE0472-JMX
R926 RES CF 100K 5% 0W166 18-CB0104-JNX
R472 RES CF 3K3 5% 0W166 18-CB0332-JNX
R927 RES CF 100K 5% 0W166 18-CB0104-JNX
R601 RES CF 3K 5% 0W166 18-CB0302-JNX
R928 RES CF 100K 5% 0W166 18-CB0104-JNX
R602 RES CF 3K 5% 0W166 18-CB0302-JNX
R929 RES CF 100K 5% 0W166 18-CB0104-JNX
R603 RES CF 2K2 5% 0W166 18-CB0222-JNX
R931 RES CF 470R 5% 0W166 18-CB0471-JNX
R604 RES CF 2K2 5% 0W166 18-CB0222-JNX
R932 RES CF 470R 5% 0W166 18-CB0471-JNX
R607 RES CF 8R2 5% 0W25 18-CD0829-JMX
R933 RES CF 75R 5% 0W166 18-CB0750-JNX
R608 RES CF 8R2 5% 0W25 18-CD0829-JMX
R934 RES CF 150R 5% 0W166 18-CB0151-JNX
61. 6 of 7
