4
Teel Operating Instructions and Parts Manual
3P740A, 4P037, 4P038, 4P039 and 4RJ96A
Teel One, Two, and Three Stage
Vertical Jet Pumps
®
E
N
G
L
I
S
H
Performance Chart (Continued)
TABLE III 4” DOUBLE PIPE DEEP WELL INSTALLATION, MODELS 4P037, 4P038, AND 4P039 SINGLE STAGE PUMPS,
EJECTOR PACKAGE 2P430 (USE 1
1
⁄4” SUCTION PIPE, 1” DRIVE PIPE)
J32P-32 20 17.5 17.5 17.5 17.5 – – – – – – – –
1/2 HP Venturi 30 13.8 11.5 9.0 6.5 – – – – – – – –
4P037 #55 40 9.5 7.0 4.5 2.0 – – – – – – – –
Nozzle 50 5.5 2.5 – – – – – – – – – –
J32P-24 20 – 10.0 9.5 8.3 6.8 5.6 4.0 2.9 – – – –
1/2 HP Venturi 30 – 8.9 7.5 6.4 5.0 4.0 2.5 1.5 – – – –
4P037 #51 40 – 6.5 5.1 4.0 3.0 1.8 0.8 – – – – –
Nozzle 50 – 4.1 3.0 2.0 1.0 – – – – – – –
J32P-18 20 – 6.0 6.0 6.0 5.2 4.3 3.6 2.3 2.2 1.7 1.2 –
1/2 HP Venturi 30 – 6.0 5.6 5.1 4.4 3.6 2.9 2.4 1.9 1.3 1.1 –
4P037 #52 40 – 4.8 4.3 3.7 3.0 2.4 1.8 1.5 1.0 0.5 0.3 –
Nozzle 50 – 3.5 2.9 2.4 1.9 1.4 0.9 0.6 0.3 – – –
J32P-33 20 23.0 20.0 16.0 – – – – – – – – –
3/4 HP Venturi 30 18.8 15.3 11.3 – – – – – – – – –
4P038 #51 40 13.0 9.8 6.0 – – – – – – – – –
Nozzle 50 6.5 – – – – – – – – – – –
J32P-32 20 – 18.3 15.0 11.3 – – – – – – – –
3/4 HP Venturi 30 – 14.9 11.3 7.6 – – – – – – – –
4P038 #51 40 – 10.0 6.4 3.0 – – – – – – – –
Nozzle 50 – 4.2 – – – – – – – – – –
J32P-24 20 – 10.6 10.5 9.6 8.7 7.3 5.8 4.2 2.5 – – –
3/4 HP
Venturi 30 – 10.3 9.6 8.5 7.0 5.6 4.3 3.0 1.7 – – –
40 – 8.6 7.5 6.5 5.2 4.0 2.9 1.8 0.8 – – –
4P038
#51 50 – 6.6 5.7 4.7 3.5 2.5 1.6 0.7 – – – –
Nozzle 60 – 4.8 4.0 3.0 2.0 1.2 – – – – – –
J32P-22 20 – 9.3 9.2 9.0 8.5 6.7 5.2 4.8 4.3 3.3 2.3 –
3/4 HP Venturi 30 – 9.2 8.8 8.3 7.3 5.9 4.7 3.9 3.1 2.3 1.3 –
4P038 #53 40 – 8.3 7.4 6.3 5.3 4.3 3.5 2.6 1.8 1.0 – –
Nozzle 50 – 6.3 5.4 4.4 3.5 2.6 1.8 1.1 – – – –
J32P-38 20 26.5 23.3 19.0 13.0 8.5 – – – – – – –
1 HP Venturi 30 22.0 19.0 14.5 9.8 8.0 – – – – – – –
4P039 #55 40 17.0 13.2 9.5 5.8 2.2 – – – – – – –
Nozzle 50 10.3 7.3 4.0 – – – – – – – – –
J32P-28 20 – 12.3 12.2 12.0 11.3 9.3 7.8 6.3 4.8 – – –
1 HP
Venturi 30 – 12.0 11.9 11.4 10.1 8.4 6.5 4.8 3.3 – – –
40 – 11.4 10.7 9.6 8.3 7.0 5.0 3.3 1.6 – – –
4P039
#55 50 – 9.7 8.5 7.2 6.0 4.8 3.3 1.6 – – – –
Nozzle 60 – 7.6 6.5 5.2 4.0 2.9 1.5 – – – – –
J32P-22 20 – 9.6 9.5 9.0 8.5 7.3 6.0 5.0 4.5 4.0 3.3 2.5
1 HP
Venturi 30 – 9.5 9.2 8.2 7.0 5.9 4.8 4.0 3.3 2.8 2.3 1.5
40 – 8.6 7.8 6.6 5.6 4.5 3.6 2.8 2.3 1.7 1.1 0.6
4P039
#53 50 – 7.0 6.1 5.2 4.2 3.3 2.5 1.8 1.3 0.8 – –
Nozzle 60 – 5.4 4.6 4.3 2.8 2.0 1.3 0.7 – – – –
Disch
Cat. Jet Press Gallons Per Minute At Depth To Water (Not Pump Setting) - In Feet
No. No. PSI 20 30 40 50 60 70 80 90 100 110 120 130
