Teeter Hang Ups EP-950 - Step Eight; Step Nine

11
ASSEMBLY
Step Nine
Attach the EZ-Angle Tether Strap
(F5-1008) to Limit the Degree of
Rotation
• Hook the clip at the end of the tether
strap to the loop at the base of the
table bed (Figure 20) to limit your
degree of rotation.
• See the Owner’s Manual insert for
further instructions on adjusting the
strap.
Figure 20
Teeter Hang Ups EP-950
Step Eight
Install the Foot Platform
Assembly
• Slide the Foot Bar (IA-1119)
with one Foot Piece (IA-
1118) in the hole below the
ratchet (Figure 18).
• Slide the Foot Piece onto the
Bar (Figure 19).
• Insert the screws (IA-1123)
onto the Foot Platform and
tighten with the screw driver
(F5-1130) (Figure 19).
Note: The Foot Pieces are
designed with a High and
Low setting. Position in the
Low setting (screws facing
up) for ease of assembly.
Refer to Owner’s Manual for
a description of the settings.
Figure 18
Figure 19
Low Setting
