ASSEMBLY
Step Seven
Install the Rear Bar Assembly
• With the rounded corners
of the rear foam Heel Cup
facing down, insert the Rear
Bar with one Heel Cup (IA-
1113) into the large hole
at the bottom of the Main
Shaft (Figure 15).
• Insert the Bolt (IA-1116) to
secure the Rear Bar to the
Main Shaft, and attach the
nut with the wrenches (F5-
1088) provided (Figure 16).
• Slip the other Heel Cup
(rounded corners down) onto
the Rear Bar and push the
Rubber Plug (F5-1056) into
the Rear Bar (Figure 17).
Figure 15
Figure 16
Figure 17
