Teeter FreeStep LT3 - Page 4

Base w/ Resistance Grip
Handles
Seat Back Assembly
Use with Step 3a
Hardware Kit (HK1045)
Handle Support Tubes
Use with Step 4b
Hardware Kit (HK1048)
Lower Seat
Use with Step 3b
Hardware Kit (HK1046)
Allen Wrench /
Screwdriver
SE1109
SE1110
Tools Provided for Assembly
SE2101 (LT1) / SE2332 (LT3)
SE1102
SE1103
Pedals
Use with Step 2 Hardware Kit (HK2044)
SE2104 (LT1) / SE2304 (LT3)
SE1106 (LT1) /
SE2306 (LT3)
SE1111 (LT1) /
SE2311 (LT3)
SE1105
SE1107 SE2108
SE1112
Rear Stabilizer
Use with Step 1a Hardware Kit (HK1042)
Console Front
Support Bar
Use with Step 4a
Hardware Kit (HK1047)
Pedal Arm Joint Cover Sets
Use with Step 5 Hardware Kit
(HK1049)
Upper Front Leg Cover Sets
Use with Step 5 Hardware Kit
(HK1049)
Rear Stabilizer Cover Set
Use with Step 1b Hardware Kit (HK1043)
2
ITEMS FOR ASSEMBLY
Parts are not shown to scale. Parts may vary slightly from images depending on model.
SE2205J
ITEM NO. ITEM NAME
ITEM NO. ITEM NAME
Base / Resistance Grip
SE2101 Base (LT1)
SE2332 Base (LT3)
SE2205J Resistance Grip
Rear Stabilizer
SE1102 Rear Stabilizer
HK1042 Step 1a Hardware Kit
Rear Stabilizer Cover Set
SE1103 Rear Stabilizer Cover (2)
HK1043 Step 1b Hardware Kit
Pedals
SE2104 Pedal (2) (LT1)
SE2304 Pedal (2) (LT3)
HK2044 Step 2 Hardware Kit
Console Front Support Bar
SE1107 Console Front Support Bar
HK1047 Step 4a Hardware Kit
Handle Support Tubes
SE2108 Handle Support Tube (2)
HK1048 Step 4b Hardware Kit
Seat Back Assembly
SE1105 Seat Back Assembly
HK1045 Step 3a Hardware Kit
Lower Seat
SE1106 Lower Seat (LT1)
SE2306 Lower Seat (LT3)
HK1046 Step 3b Hardware Kit
Pedal Arm Joint Cover Sets
SE1109 Pedal Arm Joint Cover (4)
HK1049 Step 5 Hardware Kit
Upper Front Leg Cover Set
SE1110 Upper Front Leg Cover (4)
HK1049 Step 5 Hardware Kit
Handles
SE1111 Handle (2) (LT1)
SE2311 Handle (2) (LT3)
Tools
SE1112 Allen Wrench / Screwdriver
