5-7
MAINTENANCE
Figure 2: Front Panel Controls
Ohms Range Switch
Test Voltage Range Switch
Power Switch
Test Pushbutton
3 ½ Digit Display
Test Voltage
Jack
Voltage Present
LED
Signal,
Guard &
Ground
Binding
Posts
