Tegam R1M-A - 1 Instrument Description; Purpose; Performance Characteristics

Revised August, 2004
10 TEGAM WAY • GENEVA, OHIO 44041 • 440-466-6100 • FAX 440-466-6110
• sales@tegam.com
1-1
INSTRUMENT DESCRIPTION
SECTION 1
INSTRUMENT DESCRIPTION
INTRODUCTION
1.1 Purpose
The Model RIM-A Megohmmeter is a portable instrument used
to measure high values of resistance. It is enclosed in a
rugged weather-resistant housing designed for severe
industrial and military applications.
The Model RIM-A may be used to measure resistances
between 50 kΩ and 10 GΩ with 50 V test voltage, and
between 1 MΩ and 200 GΩ with 100 V, 250 V, or 500 V test
voltage.
1.2 Performance Characteristics
This is a digital reading instrument with six resistance ranges
and four test voltage ranges.
Range
Full Scale
(Ω)
Resolution
(Ω)
Test Voltage
(V)
1
1 M
1 k
50
2
10 M
10 k
100,
250,
or 500
3
100 M
100 k
4
1 G
1 M
5
10 G
10 M
6
100 G
100 M
Table 1: Specifications
Accuracy:
Resistance accuracy on all ranges: ± 5%
Test Voltage accuracy on all ranges: ± 3%
