ELECTRICAL CONNECTION
(UK ONLY)
A) If your appliance comes fitted with a plug, it
will incorporate a 13 Amp fuse. If it does not
fit your socket, the plug should be cut off
from the mains lead, and an appropriate plug
fitted, as below.
WARNING: Very carefully dispose of the
cut off plug after removing the fuse: do not
insert in a 13 Amp socket elsewhere in the
house as this could cause a shock hazard.
With alternative plugs not incorporating a
fuse, the circuit must be protected by a 15
Amp fuse. If the plug is a moulded-on type,
the fuse cover must be re-fitted when chan-
ging the fuse using a 13 Amp Asta approved
fuse to BS 1362. In the event of losing the
fuse cover, the plug must NOT be used until
a replacement fuse cover can be obtained
from your nearest electrical dealer. The co-
lour of the correct replacement fuse cover is
that as marked on the base of the plug.
B) If your appliance is not fitted with a plug,
please follow the instructins provided below:
WARNING - THIS APPLIANCE MUST BE EAR-
THED
IMPORTANT
The wires in the mains lead are coloured in ac-
cordance with the following code:
Green and yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead
may not correspond with the coloured markings
identifying the terminals in your plug, proceed
as follows:
The green and yellow wire must be connected
to the terminal in the plug marked with the letter
E or the earth symbol or coloured green or
green and yellow.
The blue wire must be connected to the terminal
marked with the letter N or coloured black.
The brown wire must be connected to the ter-
minal marked with the letter L or coloured red.
N
E
L
