6
1 Heating indicator light. It indicates the
transmission of heat to the food and it
switches off when the set temperature has
been reached.
2 Cooker indicator light. Indicates that one or
more of electric hotplates are on.
3 Function selection.
4 Temperature selection.
5 Control knobs for the hob.
Models HC-490/HC-495/HI-435
Models HC-490 ME/HC-495 ME/HI-435 ME/HI-485 ME/HC-490 ES/HI-435 ES/HI-436 ES
Control Panel
1
3 4
1 2 3 4 5 5 5 5
1 Control Panel
2 Oven seal
3 Grill element
4 Grid
(*)
5 Tray
6 Hinge
7 Door
8 Smoke outlet
9 Fixing to unit
10 Grill screen
11 Light
12 Tempered inner
glass
1
6
12
9
11
10
7
8
2
3
5
4
(*)
Depending on the model.
