Tekmar 1773 - Page 14

- 14 -
Menu structure
1. Home display
Display
Explanation
+xx° yyy
zzzzzzzz
xx = effective slab temperature
yyy = remaining minimum heating time (0 if heating according to demand or heating off)
zzzzzzzz = current state of the ice and snow detector
2. Main menu
Display
Explanation
Basic
config.
Opens the basic configuration menu
Show status
Opens the menu for the display of the current measured values and states
Test
Opens the menu to start/stop the minimum heating time and to start a sensor measurement
Configu-
ration
Opens the configuration menu for the heating and the sensors
Administra-
tion
Opens the administration menu for the system
Back
Return to Home display
3. Basic configuration menu
Display
Explanation
Factory
default
Settings
Language
xx
Displays the set menu language; adapt setting with "Set" and then
"+" / "-"; save with "Set".
refer to "Initial
installation"
DE, EN,
FR, IT, NL,
CZ, PL
Sensor 1
Typ xxxx
Displays the setting of the connected sensor type for sensor 1;
adapt setting with "Set" and then "+" / "-"; save with "Set". When
saving the sensor type, the appropriate measurement method of
sensor 1 is set automatically to the method specified for the sensor
and the sensor state is reset automatically.
3354
3351
3352/53,
3354,
3355
3356
----
Temp Hi
Lim. xxx°
Displays the high temperature limit; adapt setting with "Set" and
then "+" / "-"; save with "Set".
+3°C
0° to +5°C
HeatTime
min.xxxm
Displays the set minimum heating time; adapt setting with "Set"
and then "+" / "-"; save with "Set". Can be set in steps of 10.
90 min.
30 to
600 min.
back
Returns to Main menu
4. Show status menu
Display
Explanation
State
--------
Displays operating state of ice and snow detector
Error
Code xx
Displays the current error code of the ice and snow detector (0 =
no error, refer to "Error codes")
Slab
Heating
Displays switching state of heating and operating hour counter
RemHeat
Tim xxxm
Displays the remaining heating time (0 if heating according to
demand or slab heating off)
Slab
T---,-°
Displays the effective slab temperature
Outdoor-
T---,-°
Displays the latest measured outdoor temperature (measured
value only available in Slab idle temperature mode)
