Tekmar 518 - User Interface; Home Screen; Symbols Description

© 2016 tekmar 518
_
D - 06/16 7 of 12
HEAT ON
Heat is turned on.
MODE OFF
The heating system is off.
WARNING SYMBOL
Indicates an error is present.
MIN
The floor is at or below the
floor minimum temperature.
MAX
The floor has reached the
floor maximum temperature.
AWAY
Operating at the away
temperature.
Home Screen
Symbols Description
User Interface
Away
