Nova 1624 Stand 113-0610-002
10. Next do the headstock end.
Note that the left most
fastenings are inserted upward
into two blind holes into the
lathe bed
11. Level the lathe - The height
could be adjusted by adjusting
the nut on the feet.
12. For further lathe assembly
instruction see main manual pg.
9-16
TEKNATOOL INTERNATIONAL
7D Dallan Place, Albany, North Shore City, Auckland, New Zealand 0632
Ph: +649-477-5600
TEKNATOOL USA INC
4200 28
th
St N, St Petersburg. FL 33714, USA
Ph: 727-954-3433 or 1-866-748-3025
WEBSITE: www.teknatool.com
Product information, technical help desk and videos.
